ABB 7BAOM3702T Air-Over Fan - TEAO 2HP, 855RPM, 60Hz
Part Number: 7BAOM3702T
Quick Summary
Air-Over Fan is a reliable 2 HP cooling solution for industrial enclosures and equipment. Maintenance delays and overheating in harsh environments are costly; this design delivers steady airflow with a compact TEAO package. CSA/UR listed and built to NEMA standards provide regulatory confidence for critical systems, while the TEAO enclosure simplifies service and reduces the need for extra housings. The unit is a 3-phase, 60 Hz motor in a 213T frame, offering straightforward integration with existing power infrastructure. In short, it combines strong performance with installation efficiency, delivering measurable business value through uptime, predictable airflow, and faster procurement.
Product Information
Extended Description
7BAOM3702T ABB: Air-Over Fan 2 Hp 208 V (AOM3702T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,855RPM,3PH,60HZ,213T,3724M,TEAO
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6307, Ball
Bearing NDE
6206
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
AOM3702T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
B
Dimension Diagram
37LYF359: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
213
Frequency (f)
60 Hz
Global Commercial Alias
AOM3702T
Gross Volume
5274.135 in³
Gross Weight
97 lb
Horsepower Rating UL/CSA
2.000 Hp
IC Class
TEAO
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
2HP,855RPM,3PH,60HZ,213T,3724M,TEAO,F1,N
Lubrication
Regreasable
Made To Order
No
Medium Description
Air-Over Fan, 2 HP, 900 RPM, Frame Size 213T, Standard Mounting, 3 Phase, TEAO Enclosure, 208-230/460 V, 60 Hz (AOM3702T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
213T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
8P
Number of Poles (High)
8
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
65 %
Product Name
Air-Over Fan
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
97 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
7.6 A | 7 A | 3.5 A
Rated Efficiency
82.50 %
Rated Speed
855 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
1.38 in
Short Description
2 HP, 900 RPM, Frame Size 213T, Standard, 3 PH, TEAO, 208-230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
900 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101105
Voltage Code
H
Voltage Rating
208 V | 230 V | 460 V
TEAO enclosure design streamlines installation and improves cooling efficiency, reducing heat buildup in cabinets and allowing straightforward mounting on standard 213T frames. This translates into faster commissioning and fewer field modifications, lowering project risk. It is well suited for control cabinets, process equipment housings, and machine enclosures where reliable airflow matters. The 3-phase, 60 Hz power range across 208–230/460 V delivers flexible integration with common plant electrical systems, minimizing cabling changes and compatibility issues across facilities. The motor’s 8-pole design delivers 855 rpm with a synchronous speed of 900 rpm, giving stable, predictable airflow that reduces thermal throttling and extends component life. Foot-mounted, horizontal mounting (F1) with a 213T frame and 1.38 in shaft diameter supports robust, vibration-tolerant installation in tight spaces. Regreasable lubrication with insulation class F and 6307 ball bearings contribute to longer service life and lower maintenance, while stock availability across multiple warehouses and a 0 day lead time shorten procurement cycles for rapid project timelines.
Get a Quick Quote for a ABB 7BAOM3702T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BAOM3702T?
Enquire Now
FAQs
Plan for horizontal, foot-mounted installation on a 213T frame (F1 orientation). Ensure alignment with the 1.38 in shaft and access for routine bearing checks (6307, Ball). The TEAO design eliminates external enclosures, simplifying cabinet mounting and airflow paths. Verify clearance for service access and confirm mounting surface compatibility with standard base plates used in industrial panels.
Yes. The motor is a three-phase, 60 Hz unit rated for 208 V, 230 V, and 460 V operation, supporting flexible connections across common industrial power systems. Ensure wiring matches the facility voltage, apply proper overcurrent protection, and follow manufacturer guidelines for starting and running currents to maintain performance and safety.
Best suited for enclosure cooling in electrical cabinets, process equipment, and industrial machines requiring reliable, low-maintenance ventilation. With 2 HP output, 855 rpm nominal speed, and TEAO enclosure, it effectively removes heat from cabinets and panels while fitting within standard 213T frame spaces and 60 Hz electrical infrastructure.
The unit is CSA/UR listed and designed to meet applicable NEMA standards, providing regulatory confidence for critical industrial systems. The TEAO enclosure and US-origin construction further support compliance with common industrial procurement requirements and safety expectations in plant environments.
Regreasable lubrication and robust bearing selection (6307, Ball) extend service intervals and reduce unplanned outages. The 82.5% rated efficiency lowers operating costs, while stock availability across multiple warehouses and 0-day lead time shorten procurement and downtime. Together, these factors deliver faster project timelines, predictable performance, and a favorable return on investment in enclosure cooling projects.
