ABB 7BCCPX18346T Explosion Proof Severe Duty motor XPFC
Part Number: 7BCCPX18346T
Quick Summary
ABB 7BCCPX18346T Explosion Proof Severe Duty motor powers heavy-duty conveyors, pumps, and mixers in hazardous industrial environments. For maintenance teams, sourcing a robust, ready-to-run solution that meets safety codes while integrating with existing electrical infrastructure is a common challenge. The design highlights include NEMA-aligned protection, IP55 ingress protection, and class F insulation, paired with an XPFC explosion-proof enclosure for added safety. Designed for rapid procurement and straightforward installation, it supports dual voltage configurations and a listed 0-day lead time, helping minimize project delays. With a compact 182Tc frame and C-face mounting, the motor enables seamless retrofits into established plant lines.
Product Information
Extended Description
7BCCPX18346T ABB: Severe Duty Motor 2 Hp 190 V (CCPX18346T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
3HP,1755//1465RPM,3PH,60HZ,182TC,XP
Invoice Description
3HP,1755//1465RPM,3PH,60HZ,182TC,XPFC,F1
Product Name
Explosion Proof Severe Duty
Product Type
Undefined
Made To Order
No
Minimum Order Quantity
1 piece
Order Multiple
1 piece
Selling Unit of Measure
piece
Country of Origin
United States (US)
Customs Tariff Number
85015220
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Medium Description
Explosion Proof Severe Duty, 3 HP, 1800//1500 RPM, Frame Size 182Tc, C-Face Mounting, 3 Phase, XPFC Enclosure, 230/460//190/380 V, 6
Short Description
3 HP, 1800//1500 RPM, Frame Size 182Tc, C-Face, 3 PH, XPFC, 230/460//190/380 V
Electrical Data
Frequency (f)
50 Hz | 60 Hz
Output Power
2 Hp | 3 Hp
Ambient Temperature
40 °C
IP Class
IP55
Insulation Class
F
Number of Poles (High)
4
Type of Duty
Continuous
Frame Material
Iron
Frame Size
182
Product Net Depth / Length
26.625 in
Product Net Height
16.25 in
Product Net Width
16.625 in
Product Net Weight
111 lb
Gross Weight
111 lb
Standards
NEMA
UNSPSC
26101112
Explosion-Proof XPFC enclosure delivers enhanced safety in hazardous areas, reducing risk of ignition and facilitating compliance with industry codes. This translates to lower incident-related downtime and simplified inspection processes on the plant floor. It's especially beneficial in chemical processing, oil and gas, and mining setups where explosion protection is mandatory. Dual voltage and horsepower range provides flexibility to match an existing drive or electrical distribution without costly rewiring, enabling faster integration with existing controls and panels. Benefits include reduced installation complexity, lower spare parts inventory, and improved uptime through standardized, readily available components. IP55 protection and insulation class F capabilities extend service life in warm or dusty environments, minimizing maintenance cycles and helping meet ongoing regulatory expectations. The 4-pole, three-phase design supports stable torque characteristics for conveyors and pumps, enhancing process consistency. Stocking across multiple warehouses and a 0-day lead time streamline project timelines and support rapid deployment in large-scale automation projects.
Get a Quick Quote for a ABB 7BCCPX18346T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCCPX18346T?
Enquire Now
FAQs
The motor supports 50 Hz and 60 Hz operation with dual voltage options of 230/460 V and 190/380 V, three-phase. This flexibility simplifies integration with existing VFDs or line power without requiring separate transformers or rewiring. Installation benefits include fewer parts, easier motor matching to drive systems, and faster commissioning in multi-voltage facilities.
Yes. The 7BCCPX18346T is designed with an XPFC explosion-proof enclosure and IP55 rating, delivering robust protection against dust and water ingress in hazardous areas. It aligns with NEMA-style protection expectations and provides a reliable solution for oil & gas, chemical, and mining environments where safety codes and explosion protection are mandatory.
The motor uses a 182Tc frame with C-face mounting, a four-pole design, and three-phase operation. This configuration supports straightforward mounting into standard base plates and common belt or direct-drive configurations. The 182Tc frame size is readily compatible with many ABB and third-party headers, enabling simpler retrofits and faster installation in existing equipment footprints.
Key standards include NEMA for enclosure and protection alignment, IP55 for ingress protection, and insulation class F for higher temperature tolerance. The XPFC designation emphasizes explosion protection, making it suitable for hazardous areas. These certifications support compliance in chemical, refining, and mining facilities and help streamline inspections and audits.
The product is listed as Active and stocked at multiple warehouses, with a stated lead time of 0 day, enabling rapid procurement. Warranty terms specify that warranty returns must be handled through the standard process. For project planning, this combination supports aggressive schedules and minimizes downtime during spares integration.
