ABB 7BCEBM3710T-D Unit Handling - Premium Efficiency
Part Number: 7BCEBM3710T-D
Quick Summary
ABB 7BCEBM3710T-D Unit Handling drives a 7.5 HP motor for automated material handling in industrial lines. Engineers often face space constraints, integration friction, and costly downtime when upgrading existing equipment. This unit carries CSA, CSA EEV, and UR certifications, plus Premium Efficiency rating and a TEFC 213TC frame, aligning with modern safety and energy standards. The combination reduces energy use, simplifies procurement, and supports reliable operation in challenging environments. By leveraging ABB's design, you gain broad warehouse stock, versatile mounting options, and a predictable supply chain that minimizes project risk. The result is faster deployment, lower total cost of ownership, and dependable performance across your critical line processes. This translates to reduced downtime, easier spare-part planning, and measurable ROI for automation upgrades.
Product Information
Extended Description
7BCEBM3710T-D ABB: Unit Handling 7.5 Hp 230 V (CEBM3710T-D)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
7.5HP,1770RPM,3PH,60HZ,213TC,3738M,
Altitude
1000 m
Ambient Temperature
40 Ā°C
Bearing
6307, Ball
Bearing NDE
6206
Brake Present
Yes
Brand / Label
Baldor-Reliance
Catalog Number
CEBM3710T-D
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
A
Dimension Diagram
37LYM907: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
213
Frequency (f)
60 Hz
Global Commercial Alias
CEBM3710T-D
Gross Volume
13438.538 inĀ³
Gross Weight
141 lb
Horsepower Rating UL/CSA
7.500 Hp
IC Class
TEFC
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
7.5HP,1770RPM,3PH,60HZ,213TC,3738M,TEFC
Lubrication
Regreasable
Made To Order
No
Medium Description
Unit Handling, 7.5 HP, 1800 RPM, Frame Size 213Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (CEBM3710T-D)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
213TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
7.5 Hp
Power Factor
80 %
Product Name
Unit Handling
Product Net Depth / Length
40.938 in
Product Net Height
18.625 in
Product Net Weight
141 lb
Product Net Width
17.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
19 A | 9.5 A
Rated Efficiency
91.70 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
1.38 in
Short Description
7.5 HP, 1800 RPM, Frame Size 213Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101115
Voltage Code
J
Voltage Rating
230 V | 460 V
7.5 HP output with 3-phase, 60 Hz operation delivers robust drive power in a compact form factor, reducing footprint in tight plant spaces while maintaining steady torque for conveyors and material-handling equipment. The TEFC enclosure coupled with a 213TC frame ensures reliable protection in demanding environments, enabling longer service intervals and lower maintenance costs. With a rated efficiency of 91.70% and a power factor of 80%, operating costs decrease and electrical compliance becomes simpler across regulatory audits, benefiting energy-intensive lines such as packaging and process automation. A service factor of 1.15 provides an extra margin for startup surges and transient loads common in high-demand systems, improving uptime and plant throughput. The motorās regreasable lubrication and durable bearings support extended life in continuous-duty applications, while the 213TC frame and C-Face drive-end flange provide straightforward installation and compatibility with standard OEM components. Stocking at multiple warehouses and a 0-day lead time minimize project risk, enabling rapid deployment on new or upgraded lines. This combination supports predictable maintenance planning, reduced spare-parts inventory, and a quicker return on investment for automation projects across food and beverage, material handling, and general manufacturing sectors.
Get a Quick Quote for a ABB 7BCEBM3710T-D
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEBM3710T-D?
Enquire Now
FAQs
Yes. This model uses a foot-mounted base with a C-Face drive end flange and horizontal mounting orientation, compatible with standard 213TC frames. Ensure the mounting surface is level, align the shaft with the driven load, and secure with appropriate fasteners. Connect to a 3-phase supply at 230 V or 460 V, and verify TEFC enclosure protection for your environment.
Key specs include 7.5 HP output, 3-phase operation at 60 Hz, dual voltage 230/460 V, rated speed around 1770 r/min, service factor 1.15, and efficiency of 91.70%. The motor has a PF of about 80%, supporting energy calculations and compliance audits for continuous-duty conveyors and processing lines.
Absolutely. The TEFC enclosure, 213TC frame, and 3P, 60 Hz design are well-suited for continuous operation in many regulatory environments. Certifications include CSA, CSA EEV, and UR, which help satisfy compliance requirements in regulated facilities. Its regreasable bearings and robust frame support long service life with predictable maintenance intervals.
This unit carries CSA, CSA EEV, and UR certifications, indicating compliance with electrical safety and energy standards across multiple markets. These endorsements simplify procurement for regulated facilities, ensure safer operation, and support documentation required for audits, insurance, and cross-border manufacturing programs.
Consider the regreasable lubrication and bearing configuration for extended life, reducing unplanned downtime. With 0-day lead time and stock at multiple warehouses, project schedules shorten and downtime costs decrease. The high efficiency and sturdy TEFC design translate to lower energy bills and longer intervals between maintenance, delivering a favorable return on investment for automation upgrades.
