ABB 7BCEDM3550 Severe Duty Motor - IE3 Premium Efficiency
Part Number: 7BCEDM3550
Quick Summary
ABB 7BCEDM3550 Severe Duty Motor provides reliable 1.50 HP power for heavy-duty industrial applications like conveyors and pumps. In harsh environments, undersized or inefficient motors spike downtime and energy costs, complicating maintenance planning. This model meets IE3 Premium efficiency, NEMA Premium, and CSA EEV certifications, delivering regulatory compliance and energy savings. Designed for 3-phase, 60 Hz operation with a TEFC enclosure and a 56C frame, it integrates smoothly with standard drive trains and service plans. With robust sealed bearings and an insulation class F construction, uptime is improved and maintenance costs stay predictable. Engineered for quick mounts and compatible with common motor bases and couplings, it supports scalable automation projects.
Product Information
Extended Description
7BCEDM3550 ABB: Severe Duty Motor 1.50 Hp 230 V (CEDM3550)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5HP,3500RPM,3PH,60HZ,56C,3520M,TE
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
CEDM3550
Certification Agency
CCSA US | CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYE4315: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
CEDM3550
Gross Volume
2110.969 in³
Gross Weight
42 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
1.5HP,3500RPM,3PH,60HZ,56C,3520M,TEFC,F1
Made To Order
No
Maximum Speed
5400 r/min
Medium Description
Dirty Duty Autophoretic, 1.5 HP, 3600 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (CEDM3550)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1.50 Hp
Power Factor
85 %
Product Name
Dirty Duty Autophoretic
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
42 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.8 A | 1.9 A
Rated Efficiency
84 %
Rated Speed
3500 r/min
Replaced Product ID (OLD)
7B35E4315M760G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
1.5 HP, 3600 RPM, Frame Size 56C, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature: 1.5 HP output with 3-phase 60 Hz operation and 230/460 V input. Business Impact: Enables seamless integration with standard industrial drives while maintaining efficient power delivery to heavy loads. Application: ideal for conveyors, pumps, and processing lines in manufacturing and packaging environments. Feature: IE3 Premium efficiency with rated efficiency around 84%. Business Impact: reduces operating costs and heat generation, improving plant cooling and energy bills. Application: continuous-duty conveyors and derived-drive systems where energy cost matters. Feature: TEFC enclosure and 56C frame construction. Business Impact: provides robust protection against dust, moisture, and dirt in dirty-duty autophoretic environments, extending bearing life. Application: outdoor or harsh indoor installations in material handling and processing. Feature: Synchronous speed 3600 r/min and Rated Speed 3500 r/min with Direct on Line starting. Business Impact: predictable performance and simple startup without complex soft-start infrastructure. Application: high-load conveyors and mixers requiring reliable ramp-up. Feature: Bearings 6205 sealed and 6203 NDE with Insulation Class F. Business Impact: lower maintenance and longer service intervals; resilience against thermal stress. Application: light-to-moderate shock environments and high-temperature facilities. Feature: 56C frame, Shaft Diameter 0.63 in, and Foot Mounting (Horizontal). Business Impact: straightforward retrofit into existing mounting footprints and easy alignment with couplings. Application: retrofit projects and new installations in standard plant layouts.
Get a Quick Quote for a ABB 7BCEDM3550
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEDM3550?
Enquire Now
FAQs
Yes. The 7BCEDM3550 uses a 56C frame and foot-mounted design, enabling straightforward installation on standard motor bases. It supports direct-on-line starting and is compatible with common 3-phase 60 Hz VFDs, simplifying integration with existing drives and control schemas while minimizing mounting adaptations.
The motor delivers 1.5 HP with a rated speed of 3500 r/min and a synchronous speed of 3600 r/min. It achieves IE3 Premium efficiency (approx. 84%), with a service factor of 1.15, and operates on 230/460 V at 60 Hz, suitable for continuous-duty applications in demanding environments.
Yes. The TEFC (Total Envelope Fan Cooled) enclosure and sealed bearings (6205) are engineered for dirty-duty autophoretic environments, protecting internal components from dust, moisture, and contaminants while maintaining reliable performance in rugged processing and material handling systems.
The 7BCEDM3550 carries IE3 Premium efficiency, NEMA Premium, and CSA EEV certifications, with CSA US and UR recognitions noted in supplier information. These certifications help ensure regulatory compliance, energy savings, and safer operation in certified industrial environments.
Energy efficiency reduces operating costs, while rugged TEFC construction and sealed bearings extend service intervals. The combination of durable components, lower heat, and straightforward mounting lowers maintenance labor and spare parts needs, contributing to a faster payback in facilities with continuous or high-demand duty cycles.
