ABB 7BCEDM3558T Motors - IE3 Premium Efficiency (NEMA 12-12)
Part Number: 7BCEDM3558T
Quick Summary
ABB 7BCEDM3558T is a 2 HP severe-duty motor designed for demanding industrial drives and equipment. In harsh environments, downtime and energy waste erode uptime and total cost of ownership. This motor carries certifications including NEMA Premium Efficiency (IE3), CSA/UR recognition, and CCSA US approval, ensuring regulatory compliance and reliable performance. With a TEFC enclosure, 145TC frame, and 230/460 V three-phase capability, it delivers robust operation while simplifying OEM integration, service, and maintenance planning for conveyors, pumps, and heavy-duty mixers.
Product Information
Extended Description
7BCEDM3558T ABB: Severe Duty Motor 2 Hp 230 V (CEDM3558T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1760RPM,3PH,60HZ,145TC,3528M,TE
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
CEDM3558T
Certification Agency
CCSA US | CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYE4328: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
CEDM3558T
Gross Volume
3496.049 in³
Gross Weight
52 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
2HP,1760RPM,3PH,60HZ,145TC,3528M,TEFC,F1
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
Dirty Duty Autophoretic, 2 HP, 1800 RPM, Frame Size 145Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (CEDM3558T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
145TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
77 %
Product Name
Dirty Duty Autophoretic
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
52 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.6 A | 2.8 A
Rated Efficiency
86.50 %
Rated Speed
1760 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Short Description
2 HP, 1800 RPM, Frame Size 145Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature: IE3 Premium Efficiency and 2 HP output → Business Impact: Lower energy consumption and reduced operating costs over the motor’s life → Application: Conveyor belts, pumps, and process equipment in continuous-duty environments benefit from energy savings and quieter operation. Feature: TEFC enclosure with 145TC frame and 3-phase 60 Hz operation → Business Impact: Enhanced protection against dust, moisture, and contaminants while ensuring consistent performance in rugged facilities → Application: Dirty-duty plants, chemical processing lines, and outdoor installations where enclosure integrity matters. Feature: NEMA design B, 4-pole, 1760 r/min rated speed with direct-on-line starting → Business Impact: Predictable torque and simple, cost-effective commissioning with reliable startup in mission-critical lines → Application: Material handling, fans, and pumps requiring robust cold-start capability. Feature: Sealed bearings (6205) and insulation class F → Business Impact: Longer service life, reduced maintenance intervals, and improved insulation performance in high-temperature environments → Application: Heavy-load conveyors and mixers where high reliability is essential. Feature: Foot-mounted with C-face drive end flange (C-Face) and 230/460 V compatibility → Business Impact: Easy retrofits and quick installation in existing OEM systems with minimal downtime → Application: Retrofit projects and new installations across automotive, packaging, and metalworking sectors. Feature: Stocked at multiple warehouses with 0 day lead time → Business Impact: Fast delivery, reduced downtime, and improved project scheduling → Application: Just-in-time manufacturing lines and urgent maintenance missions.
Get a Quick Quote for a ABB 7BCEDM3558T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEDM3558T?
Enquire Now
FAQs
The 7BCEDM3558T uses a 145TC frame with a foot-mounted base and a C-Face drive end flange, set for horizontal mounting. For easiest retrofit, align bolt holes with the existing base pattern, ensure proper coupling and guard clearance, and verify the 230/460 V three-phase supply is wired for direct-on-line starting. The TEFC enclosure helps protect internal components in dirty environments, reducing long-term maintenance. Always follow OEM installation manuals and local electrical codes for safe startup and commissioning.
This motor delivers 2 HP with a rated speed of 1760 r/min (4P, 60 Hz) and a maximum speed of 2700 r/min. It achieves 86.50% rated efficiency and a service factor of 1.15, with rated current of 5.6 A (running) and 2.8 A (stalled/low-load condition). The IE3 premium efficiency aligns with modern energy regulations, making it suitable for long-running, energy-conscious applications.
Yes. The motor features a TEFC enclosure, a rugged 145TC frame, and heavy-duty bearings designed for continuous operation in challenging environments. With a 60 Hz, 230/460 V three-phase supply and C-face mounting, it can withstand dust, moisture, and temperature variations, reducing the risk of thermal buildup and bearing wear. This makes it a strong choice for conveyors, material handling, and processing lines in dirty or harsh plants.
The 7BCEDM3558T carries CSA US, CSA EEV, UR, and NEMA Premium efficiencies, among others, ensuring compliance with regional safety and energy standards. These certifications validate safe electrical design, reliable performance under standard industrial conditions, and superior energy efficiency. For procurement and installation, they support regulatory alignment, warranty coverage, and easier OEM acceptance across North American facilities.
The IE3 efficiency rating reduces operating costs over the motor life, while sealed bearings and a robust TEFC enclosure lower maintenance frequency and downtime. Combined with stock availability and 0 day lead times, you gain improved uptime, faster repairs, and a faster return on investment, particularly on energy-intensive conveyors, pumps, and process equipment in continuous-duty service.
