ABB 7BCEM2532T General Purpose Motor - OPSB Enclosure
Part Number: 7BCEM2532T
Quick Summary
General Purpose Motor ABB 7BCEM2532T delivers reliable three‑phase power for industrial drives like pumps and conveyors. Engineers often battle downtime and performance drift; this motor mitigates that with a robust OPSB enclosure, 60 Hz capability, and a rugged 324TC frame designed for continuous operation. It carries CSA and UR certifications, including CSA EEV labeling, with NEMA‑related efficiency guidance to support cross‑market compliance. By aligning with Premium Efficiency standards and standard 230/460 V operation, it reduces energy waste while simplifying procurement. For OEMs and maintenance teams, the combination of easy installation, proven reliability, and readily available stock translates to faster project timelines and lower total cost of ownership.
Product Information
Extended Description
7BCEM2532T ABB: General Purpose Motor 25 Hp 230 V (CEM2532T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
25HP,1180RPM,3PH,60HZ,324TC,OPSB,F1
Ambient Temperature
40 °C
Bearing
6312 | Ball
Bearing NDE
6309 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CEM2532T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
40LYH006: Dimension Sheet
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
OPSB
Frame Material
Steel
Frame Size
324
Frequency (f)
60 Hz
Global Commercial Alias
CEM2532T
Gross Volume
14448.906 in³
Gross Weight
383 lb
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
Insulation Class
F
Invoice Description
25HP,1180RPM,3PH,60HZ,324TC,OPSB,F1
Made To Order
No
Medium Description
General Purpose 3PH Open, 25 HP, 1200 RPM, Frame Size 324Tc, C-Face Mounting, 3 Phase, OPSB Enclosure, 230/460 V, 60 Hz (CEM2532T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
324TC
Motor Frame Suffix
TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
25 Hp
Power Factor
76 %
Product Name
General Purpose 3PH Open
Product Net Depth / Length
31 in
Product Net Height
19.625 in
Product Net Weight
383 lb
Product Net Width
23.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
68 A | 34 A
Rated Efficiency
93 %
Rated Speed
1180 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
2.13 in
Short Description
25 HP, 1200 RPM, Frame Size 324Tc, C-Face, 3 PH, OPSB, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: 25 HP at 1180 rpm and 60 Hz delivers solid, consistent torque for medium‑duty loads such as conveyors and pumps, reducing startup spikes and improving process stability across manufacturing lines. This performance supports predictable maintenance windows and lower energy consumption thanks to 93% rated efficiency and 76% power factor, enabling tighter electrical budgeting and reduced utility impact on line operations. Feature → Business Impact → Application: OPSB enclosure and C‑Face mounting provide rugged protection in dusty, shop‑floor environments while enabling straightforward mounting on existing bases; this simplifies retrofit projects and minimizes installation downtime in retrofits or new line builds. Feature → Business Impact → Application: 324TC frame with foot mounting and horizontal orientation aligns with common equipment footprints, easing replacement or upgrade within legacy systems and ensuring compatibility with standard gearbox and coupling configurations for pumps and fans. Feature → Business Impact → Application: 230/460 V dual voltage and direct on line starting support fast commissioning with minimal drive equipment, decreasing commissioning time and enabling rapid production ramp‑ups. Feature → Business Impact → Application: CSA, UR, and CSA EEV certifications—along with NEMA guidelines—provide regulatory confidence for global deployments, reducing risk in multi‑site installations and aiding compliance documentation for audits. Feature → Business Impact → Application: Stocked at multiple warehouses with 0 day lead time improves spare‑part availability and reduces downtime risk during peak demand, making it ideal for OEMs managing just‑in‑time manufacturing goals.
Get a Quick Quote for a ABB 7BCEM2532T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEM2532T?
Enquire Now
FAQs
The ABB 7BCEM2532T uses a 324TC frame with C‑Face mounting and foot mounting options, designed for horizontal orientation. Ensure a compatible base, sufficient clearance for the OPSB enclosure, and proper shaft alignment with existing gear or coupling assemblies. Verify voltage setpoints of 230 or 460 V and confirm enclosure protections match your environment.
This is a three‑phase motor rated at 25 HP with a synchronous speed of 1200 r/min and a rated speed of 1180 r/min. It operates at 230 V or 460 V, has a power factor around 76% and a rated efficiency near 93%, and supports direct on line starting for quick commissioning in standard industrial drives.
The motor carries CSA, UR, and CSA EEV certifications, with NEMA compatibility guidance. These marks validate electrical safety and performance for North American markets and support regulatory compliance in global sites, reducing qualification time for new installations and easing cross‑site procurement.
Yes. The motor is specified for Continuous duty with a duty time rating of 60 minutes, and it features a robust OPSB enclosure and steel frame that withstands typical factory environments. Its premium efficiency and solid bearing system further support reliable, long‑term operation with minimal unscheduled downtime.
Ideal for general purpose open motor applications such as pumps, fans, and conveyors in manufacturing and processing lines. The 324TC frame, C‑Face mounting, and OPSB housing make it a strong fit for OEM equipment retrofits and new line installations requiring reliable start‑up, easy maintenance, and compliance with industry standards.
