ABB 7BCEM2549T-G Shaft Ground - Premium Efficiency
Part Number: 7BCEM2549T-G
Quick Summary
Shaft Ground is a 75 HP, three-phase motor designed for robust shaft grounding in demanding industrial drives. This solution helps reduce grounding-related EMI and downtime, delivering reliable performance in applications such as conveyors, pumps, and fans. The unit carries CSA EEV, UR, and NEMA Premium Efficiency certifications to meet regulatory and energy-efficiency expectations. With stock available across multiple warehouses and a 0 day lead time for many locations, it provides a practical balance of availability, installation ease, and long-term cost of ownership for OEMs and maintenance teams.
Product Information
Extended Description
7BCEM2549T-G ABB: Shaft Ground 75 Hp 230 V (CEM2549T-G)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
75HP,3535RPM,3PH,60HZ,364TSC,OPSB,F
Ambient Temperature
40 °C
Bearing
6313
Bearing NDE
6311
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CEM2549T-G
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Drive End Flange Type
C-Face
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
OPSB
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
CEM2549T-G
Gross Volume
14448.906 in³
Gross Weight
472 lb
Insulation Class
H
Invoice Description
75HP,3535RPM,3PH,60HZ,364TSC,OPSB,F1
Made To Order
No
Medium Description
Shaft Ground, 75 HP, 3600 RPM, Frame Size 364Tsc, C-Face Mounting, 3 Phase, 230/460 V, 60 Hz (CEM2549T-G)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
364TSC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
75 Hp
Power Factor
90 %
Product Name
Shaft Ground
Product Net Depth / Length
31 in
Product Net Height
19.625 in
Product Net Weight
472 lb
Product Net Width
23.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
168 A | 84 A
Rated Efficiency
93.60 %
Rated Speed
3535 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.88 in
Shaft Grounding
Shaft Grounding
Short Description
75 HP, 3600 RPM, Frame Size 364Tsc, C-Face, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature: shaft grounding design reduces stray currents and EMI, lowering bearing wear and process interruptions. Benefit: improved motor life and reduced maintenance cost in continuous-duty applications. Application: ideal for conveyors and heavy machinery where electrical noise and grounding integrity are critical. Feature: Premium Efficiency rating (93.60%) lowers operating energy consumption over the motor’s life. Benefit: measurable energy cost savings and compliance with energy-performance targets. Application: large-capacity fans, pumps, and material handling equipment with 60 Hz operation. Feature: robust 364TSC frame with OPSB enclosure and steel frame construction enhances durability in harsh environments. Benefit: reliable operation in temperature up to 40 °C and minimal enclosure-related thermal risk. Application: manufacturing floors and industrial plants with demanding ambient conditions. Feature: versatile electricals 230 V / 460 V and 60 Hz, along with direct-on-line starting. Benefit: simplified electrical design, faster installation, and lower upfront hardware costs. Application: retrofit projects and new line builds requiring quick commissioning. Feature: foot-mounted, C-face mounting with 1.88 in shaft diameter and 75 HP output. Benefit: straightforward alignment and compatibility with common conveyor and pump housings. Application: retrofit and new installations in standard plant footprints.
Get a Quick Quote for a ABB 7BCEM2549T-G
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEM2549T-G?
Enquire Now
FAQs
The motor is foot-mounted with a C-face flange, designed around the 364TSC frame and OPSB enclosure. It supports horizontal mounting and direct-on-line starting, simplifying integration with conveyors, pumps, and fans in standard plant footprints.
Rated at 75 HP with 3535 r/min, it operates on 60 Hz at 230/460 V. It features a 3-phase design, 1.88 in shaft diameter, 93.60% efficiency, and a service factor of 1.15. The motor also uses a 364TSC frame and OPSB enclosure for rugged duty.
Yes. The ABB 7BCEM2549T-G carries CSA EEV, UR, and NEMA Premium efficiency labeling, ensuring regulatory compliance, energy savings, and reliability in commercial and industrial environments.
It excels in continuous-duty applications such as conveyors, pumps, and fans where grounding integrity and EMI control are important. The footprint and mounting options also suit retrofit projects and new line builds in manufacturing facilities.
Lead time is listed as 0 day for stocked locations, with multiple warehouses showing stock availability. This enables rapid procurement and reduced downtime for maintenance and production lines.
