ABB 7BCEM31155 General Purpose Motor - IE3 Premium
Part Number: 7BCEM31155
Quick Summary
ABB 7BCEM31155 general purpose motor delivers 2 HP, 230 V three-phase power for open-enclosure drivetrain applications. Operators often face unexpected downtime and rising energy costs when motors aren’t matched to load and duty. This model aligns with IE3 Premium Efficiency, NEMA B design, and standard 56C frame markings to ensure reliable performance. In practice, it supports OEMs and maintenance teams seeking predictable lead times and lower total cost of ownership. With a 60 Hz specification, 3450 rpm rated speed, and a 2 HP output, it suits conveyors, pumps, and fans. Its 230/460 V capability and 56C frame simplify replacement and drive system integration across plants.
Product Information
Extended Description
7BCEM31155 ABB: General Purpose Motor 2 Hp 230 V (CEM31155)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,3450RPM,3PH,60HZ,56C,3524M,OPEN
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CEM31155
Certification Agency
C UR US ENERGY
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYZ564: Dimension Sheet
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
CEM31155
Gross Volume
3496.049 inÂł
Gross Weight
43 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
2HP,3450RPM,3PH,60HZ,56C,3524M,OPEN,F1,N
Made To Order
No
Medium Description
General Purpose 3PH Open, 2 HP, 3600 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, OPEN Enclosure, 230/460 V, 60 Hz (CEM31155)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Motor Frame Suffix
C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
85 %
Product Name
General Purpose 3PH Open
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
43 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.2 A | 2.6 A
Rated Efficiency
85.50 %
Rated Speed
3450 r/min
Replaced Product ID (OLD)
7B35Z564S254G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
2 HP, 3600 RPM, Frame Size 56C, C-Face, 3 PH, OPEN, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The motor delivers 2 HP at 230/460 V with 60 Hz operation, enabling efficient power delivery and compatibility with common plant voltages, reducing wiring complexity and installation time for new or replacement drives. This translates to measurable energy savings and easier procurement for OEMs and maintenance teams working on open-enclosure conveyors and pumps. Application: general purpose service in mixed-duty environments, open enclosures, and C-face mounting. Feature → Business Impact → Application: IE3 Premium efficiency, insulation class F, and NEMA design B improve long-term energy performance and thermal reliability, reducing operating costs and extending motor life in continuous duty scenarios. Application: continuous-duty fans, pumps, and process equipment. Feature → Business Impact → Application: 56C frame, foot mounting with C-Face compatibility simplifies retrofits and upgrades within existing bolt-pattern standards, accelerating installation and minimizing downtime in automation lines. Application: retrofit projects and new equipment in conveyors and packaging lines. Feature → Business Impact → Application: Direct On Line starting capability and 3-phase 60 Hz operation support straightforward startup in typical plant environments, lowering commissioning risk. Application: OEM assemblies and field service starts. Feature → Business Impact → Application: 0 day lead time and stock availability at multiple warehouses enhance uptime and spare-part readiness, enabling rapid deployment of critical equipment across manufacturing floors.
Get a Quick Quote for a ABB 7BCEM31155
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEM31155?
Enquire Now
FAQs
The 7BCEM31155 uses a 56C frame with C-Face mounting and foot-mounted orientation. It supports direct-on-line starting and 3-phase connections at 230/460 V, 60 Hz. When retrofitting, ensure bolt patterns align with standard 56C footprints, verify shaft diameter of 0.63 in, and confirm clearance for OPEN enclosure cooling and service access.
Key specs include 2 HP output, 3450 r/min nominal speed at 60 Hz, voltage 230/460 V, and a power factor of about 0.85. Equipped with IE3 Premium efficiency and insulation class F, the motor delivers lower running losses, reduced heat generation, and improved overall energy efficiency over a typical NEC motor, enhancing long-term operational cost savings.
Yes. The 7BCEM31155 is designed for continuous duty with an OPEN enclosure, 56C frame, and 3-phase operation. Its NEMA Design B, insulation class F, and IE3 Premium efficiency support reliable operation under steady loads, while the open design allows effective cooling in standard industrial environments.
The motor aligns with NEMA design standards (B), features IE3 Premium efficiency, and is specified for use in US-sourced assemblies. Its data also references a UL/CSA-style regulatory path via certification agency notes, ensuring suitability for industrial installations in North America and compatible with common compliance expectations.
Warranty terms typically require proper handling of warrantyed components, with returns for faulty units. Stocked availability (0 day lead time) minimizes downtime and accelerates service. ROI benefits come from IE3 efficiency, reduced energy consumption, and lower maintenance costs due to robust design, long-life bearings, and standard frame compatibility for easy replacement in existing lines.
