ABB 7BCEM3116T General Purpose Motor - IE3 Premium
Part Number: 7BCEM3116T
Quick Summary
ABB 7BCEM3116T General Purpose Motor drives reliable 1 HP, 230 V operation for general purpose drive systems in manufacturing. Engineers frequently contend with downtime from incompatible motors and rising energy costs that erode plant efficiency and throughput. This model carries IE3 premium efficiency, CSA and UR safety certifications, along with a NEMA design code B rating, ensuring regulatory compliance and durability. With dual voltage support, a compact 143TC frame, C-face and foot mounting, and an OPSB open enclosure, it fits modern open-drive installations and retrofits while lowering total cost of ownership. The combination of regreasable bearings and 60 Hz operation across 230/460 V gives reliable performance in continuous service across a range of industrial applications.
Product Information
Extended Description
7BCEM3116T ABB: General Purpose Motor 1 Hp 230 V (CEM3116T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,1770RPM,3PH,60HZ,143TC,3520M,OP
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CEM3116T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
B
Dimension Diagram
35LYBB102: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
OPSB
Frame Material
Steel
Frame Size
143
Frequency (f)
60 Hz
Global Commercial Alias
CEM3116T
Gross Volume
2110.969 inÂł
Gross Weight
35 lb
Horsepower Rating UL/CSA
1.000 Hp
IC Class
OPSB
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
1HP,1770RPM,3PH,60HZ,143TC,3520M,OPSB,F1
Lubrication
Regreasable
Made To Order
No
Medium Description
General Purpose 3PH Open, 1 HP, 1800 RPM, Frame Size 143Tc, C-Face Mounting, 3 Phase, OPSB Enclosure, 230/460 V, 60 Hz (CEM3116T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
143TC
Motor Frame Suffix
TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
69 %
Product Name
General Purpose 3PH Open
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
35 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.2 A | 1.6 A
Rated Efficiency
85.50 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.88 in
Short Description
1 HP, 1800 RPM, Frame Size 143Tc, C-Face, 3 PH, OPSB, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101112
Voltage Code
L
Voltage Rating
230 V | 460 V
Feature: 1 HP, 230/460 V, 3-phase operation provides dual-voltage flexibility for a wide range of equipment. Business Impact: simplifies spare parts, reduces wiring changes during upgrades, and improves energy efficiency across variable loads. Application: ideal for general purpose drives on conveyors, pumps, and fans in manufacturing environments. Feature: IE3 Premium Efficiency and a 69% power factor profile reduce operating costs and improve compliance with energy standards. Business Impact: lower energy bills, reduced heat generation, and easier regulatory alignment in plant energy audits. Application: continuous-duty motors on process lines and packaging systems. Feature: OPSB enclosure with a 143TC frame, C-face and foot mounting. Business Impact: robust protection and easier installation in open manufacturing spaces, supporting quick retrofits and scalable line upgrades. Application: new installations and retrofits in automation cells. Feature: Regreasable bearings (6205 | 6203) and a 0.88 in shaft diameter. Business Impact: extended bearing life, lower maintenance costs, and reduced unscheduled downtime. Application: high-cycle conveyors, mixers, and fans. Feature: Direct On Line starting and 60 Hz operation. Business Impact: simplified start-up, fewer components, and reliable engagement with minimal torque ripple. Application: line-starts on standard industrial drives. Feature: 143TC frame, 3-phase, 60 Hz, dual voltage, and 1.15 service factor. Business Impact: flexible installation across a spectrum of equipment with a safety margin for overloads. Application: general purpose motors on multiple process equipment in plants.
