ABB 7BCEM3708T-G Shaft Ground - 5HP, TEFC, 60Hz
Part Number: 7BCEM3708T-G
Quick Summary
Shaft Ground ABB 7BCEM3708T-G is a grounding accessory for 5 HP motors used in industrial drives. Many plants struggle with nuisance shocks and bearing wear caused by improper grounding, leading to unplanned downtime. This unit carries CSA, CSA EEV, and UR certifications for North American compliance, supporting safe, auditable operations. Designed for 230/460 V, 60 Hz operation with a TEFC enclosure and 215TC frame, it integrates with Baldor-Reliance 3‑phase systems and simplifies procurement. By aligning with premium efficiency standards and NEMA guidelines, it delivers tangible business value through safer equipment and longer motor life, while enabling faster maintenance cycles and better overall uptime.
Product Information
Extended Description
7BCEM3708T-G ABB: Shaft Ground 5 Hp 230 V (CEM3708T-G)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1160RPM,3PH,60HZ,215TC,TEFC,F1
Ambient Temperature
40 °C
Bearing
6307 | Ball
Bearing NDE
6206 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CEM3708T-G
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
07LYM068: Dimension Sheet
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Iron
Frame Size
215
Frequency (f)
60 Hz
Global Commercial Alias
CEM3708T-G
Gross Volume
9144.346 in³
Gross Weight
154 lb
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
Insulation Class
H
Invoice Description
5HP,1160RPM,3PH,60HZ,215TC,TEFC,F1
Made To Order
No
Medium Description
Shaft Ground, 5 HP, 1200 RPM, Frame Size 215Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (CEM3708T-G)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
215TC
Motor Frame Suffix
TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
74 %
Product Name
Shaft Ground
Product Net Depth / Length
28.625 in
Product Net Height
17.625 in
Product Net Weight
154 lb
Product Net Width
18.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
14.2 A | 7.1 A
Rated Efficiency
89.50 %
Rated Speed
1160 r/min
Replaced Product ID (OLD)
7B07-0000-0412
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.38 in
Shaft Grounding
Shaft Grounding
Short Description
5 HP, 1200 RPM, Frame Size 215Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: Shaft Grounding design reduces stray currents and bearing damage, improving motor longevity and reducing maintenance costs; ideal for conveyor lines and pump stations where reliable grounding is critical. Feature → Compatibility → Application: 215TC frame with C-Face mounting and 230/460 V 60 Hz compatibility enables straightforward retrofit on existing Baldor-Reliance 5 HP motors, minimizing downtime during upgrades. Feature → Enclosure & Build → Application: TEFC enclosure blocks dust and moisture, enhancing reliability in harsh industrial environments such as packaging lines and material handling. Feature → Certifications → Application: CSA EEV and UR certifications support regulatory compliance during audits and in regulated sectors like food & beverage and automotive manufacturing, reducing procurement risk. Feature → Stock & Lead Time → Application: 0 day lead time with multiple warehouse stock such as US and China facilities improves project schedules and just-in-time deliveries for large deployments.
Get a Quick Quote for a ABB 7BCEM3708T-G
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEM3708T-G?
Enquire Now
FAQs
Install the Shaft Ground on 5 HP, 3‑phase motors with a 215TC frame and C‑Face mounting. Ensure compatibility with 230/460 V supplies and a TEFC enclosure. Verify motor shaft diameter (1.38 in) and align the grounding connector per Baldor-Reliance installation guidelines to maximize safety and minimize downtime.
Yes. The unit is designed for 215TC frame, C‑Face mounting, 230/460 V, 60 Hz, 3‑phase motors. It integrates with Baldor‑Reliance motors and supports straightforward retrofits, reducing wiring changes and installation time while preserving motor performance.
The Shaft Ground carries CSA, CSA EEV, and UR certifications. These markings support compliance in North America, simplify supplier qualification, and assist in regulatory audits for industries such as food & beverage, automotive, and general manufacturing.
By reducing bearing currents and electrical noise, the grounding accessory can extend bearing life and reduce unplanned downtime. The result is lower maintenance costs, less frequent motor replacements, and improved uptime for critical lines like conveyors and pumps, delivering faster payback on motor upgrade projects.
Yes. The TEFC enclosure and 60 Hz operation are suitable for demanding environments. With a 215TC frame and 230/460 V support, it works across standard Baldor-Reliance 3‑phase motors in manufacturing, packaging, and material handling where reliable grounding is essential.
