ABB 7BCENM3546 General Purpose Motor - IE3 3PH Enclosed
Part Number: 7BCENM3546
Quick Summary
General Purpose Motor ABB delivers reliable 1 HP three-phase service for general machinery such as pumps and conveyors. Manufacturers often struggle with compatibility, rapid procurement, and maintenance when sourcing motors for mixed equipment fleets. This model aligns with IE3 Premium Efficiency and is certified by CSA, CSA EEV, and UR, while adhering to NEMA design standards for dependable performance. With a dual voltage rating of 230/460 V at 60 Hz and a 56C frame, it fits a wide range of applications while simplifying spare parts and stocking. Selecting this motor supports energy savings, improved uptime, and streamlined procurement across industrial fleets.
Product Information
Extended Description
7BCENM3546 ABB: General Purpose Motor 1 Hp 230 V (CENM3546)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,1770RPM,3PH,60HZ,56C,3522M,TENV
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CENM3546
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
35LYE012: Dimension Sheet
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
CENM3546
Gross Volume
2110.969 in³
Gross Weight
38 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
1HP,1770RPM,3PH,60HZ,56C,3522M,TENV,F1,N
Made To Order
No
Medium Description
General Purpose 3PH Enclosed, 1 HP, 1800 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (CENM3546)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Motor Frame Suffix
C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
66 %
Product Name
General Purpose 3PH Enclosed
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
38 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.34 A | 1.67 A
Rated Efficiency
85.50 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
1 HP, 1800 RPM, Frame Size 56C, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature IE3 Premium Efficiency is paired with precise winding design to reduce running costs and heat buildup, delivering measurable energy savings for continuous operations such as conveyors and pumps. Business Impact lower energy bills over the motor’s life and improved thermal performance; Application ideal for light to moderate-load general equipment in manufacturing environments. Enclosure Type TENV protects the windings from dust and moisture, reducing maintenance needs and extending service intervals in harsh factory conditions; Application suitable for general purpose motors operating in dusty or humid spaces. Frame Size 56C with C-Face mounting provides a compact, standard-footprint solution that simplifies retrofits and alignment with couplings and gearboxes; Business Impact faster installations and easier maintenance, reducing downtime in repair cycles. Voltage Rating 230/460 V and Frequency 60 Hz enable flexible electrical supply options and easier stock management; Application supports multi-voltage facilities and simplifies wiring in mixed fleets. Bearings 6205 Ball and 6203 Ball with Insulation Class F deliver long bearing life and reliable insulation under moderate ambient temperatures; Business Impact lower replacement costs and higher uptime in continuous service. Service Factor 1.15 and NEMA design support robust performance under load variability; Application beneficial for conveyors, fans, and pumps subject to transient loads. Weight 38 lb and Dimension Diagram reference provide designers with a clear footprint for enclosure integration and rack mounting; Application reduces installation surprises and ensures compliant enclosure planning.
Get a Quick Quote for a ABB 7BCENM3546
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCENM3546?
Enquire Now
FAQs
The motor uses 56C frame size with C-Face mounting and foot-mounted base, allowing straightforward alignment with standard couplings and gearboxes. This simplifies retrofits and new installations alike, reducing setup time and ensuring compatibility with common drivetrain components.
It is a 3-phase, 60 Hz motor rated at 1 HP with dual voltage of 230 V / 460 V. The synchronous speed is 1800 r/min, with a rated speed around 1770 r/min and an IE3 Premium Efficiency rating, suitable for a wide range of general machinery.
Yes. The motor is designed for continuous duty (duty time 60 minutes) with a service factor of 1.15 and a TENV enclosure. Its robust bearings and insulation class F support reliable operation under constant load in conveyors and pump systems.
This motor carries IE3 Premium Efficiency, CSA, CSA EEV, and UR certifications, along with NEMA design compliance. These markings help meet safety, energy, and regulatory requirements in many industrial settings and support easier supplier qualification.
Lead time is listed as 0 day, with stock available at multiple warehouses including US and China. Minimum order quantity is 1 piece, and the motor weighs about 38 lb, aiding quick procurement and on-site handling.
