ABB 7BCESWDM3558 Washdown Motor - Premium Efficiency
Part Number: 7BCESWDM3558
Quick Summary
ABB washdown motor 7BCESWDM3558 delivers reliable, washdown-ready power for hygienic manufacturing environments. In harsh washdown settings, corrosion, downtime, and inconsistent performance threaten uptime and product quality. It carries CSA, CSA EEV, and UR certifications, ensuring safety, reliability, and regulatory compliance across North American facilities. This 2 HP, 3-phase TEFC motor is designed for 60 Hz operation with 230/460 V capability, meeting the demands of modern automation lines. By combining stainless frame components, a paint-free finish, and premium efficiency, it reduces energy use, lowers maintenance costs, and extends service intervals. For OEMs and maintenance teams, the result is increased line uptime and predictable, long-term total cost of ownership.
Product Information
Extended Description
7BCESWDM3558 ABB: Washdown Motor 2 Hp 230 V (CESWDM3558)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1760RPM,3PH,60HZ,56C,3528M,TEFC
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CESWDM3558
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYS641: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Stainless Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
CESWDM3558
Gross Volume
3496.049 inÂł
Gross Weight
45 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
2HP,1760RPM,3PH,60HZ,56C,3528M,TEFC,F1,N
Made To Order
No
Medium Description
Paint-Free Washdown, 2 HP, 1800 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (CESWDM3558)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
75 %
Product Name
Paint-Free Washdown
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
45 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.8 A | 2.9 A
Rated Efficiency
86.50 %
Rated Speed
1750 r/min
Replaced Product ID (OLD)
7B35S641G073G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
2 HP, 1800 RPM, Frame Size 56C, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature: TEFC enclosure, paint-free finish, and stainless steel frame protect the motor from washdown chemicals and corrosion, extending service life in hygienic environments. Business Impact: Reduced maintenance frequency and lower replacement costs, delivering a lower total cost of ownership. Application: Food processing, pharmaceutical packaging, and other critical washdown lines where cleanliness and reliability are essential. Feature: 3-phase operation with 60 Hz power and dual voltage rating of 230 V / 460 V ensures seamless integration with North American electrical systems. Business Impact: Simplified installation and wiring, faster commissioning, and lower spare-part complexity. Application: OEM equipment and retrofit projects in U.S. facilities. Feature: Premium Efficiency (86.50%) with 1.15 service factor and NEMA B design reduce energy consumption and improve torque reserve during startup. Application: High-demand conveyors and automated handling in packaging and processing lines. Business Impact: Energy cost savings, improved process stability, and compliant performance under variable loads. Feature: Direct On Line starting, 56C frame, and TEFC enclosure support robust, easy installation and maintenance. Business Impact: Fast startup, reduced electrical disturbance, and longer motor life. Application: Conveyor drives, fans, and pumps across continuous-duty environments. Feature: 0 day lead time stock across multiple warehouses and a 2 HP, paint-free build. Application: Rapid deployment for urgent maintenance or expansion, minimizing downtime. Business Impact: Masoned uptime, predictable delivery, and improved production planning. Feature: Compatibility with foot-mounted, horizontal orientation (F1) and C-Face drive end flange type enables flexible mounting options. Business Impact: Easier retrofits and compatibility with a wide range of existing equipment in process lines. Application: Retrofit projects and new line installations in hygienic plants.
Get a Quick Quote for a ABB 7BCESWDM3558
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCESWDM3558?
Enquire Now
FAQs
This motor supports 230/460 V in a 3-phase, 60 Hz configuration and uses Direct On Line starting. Ensure supply voltage matches the nameplate, connect three-phase power, and mount using the 56C frame with a TEFC enclosure. Choose the correct horizontal mount (F1) or C-face flange per your drive system, and confirm bearing seals for washdown compatibility.
Key specs include 2 HP output, rated speed around 1750 r/min (Synchronous speed 1800 r/min), 56C frame, TEFC enclosure, 3-phase 60 Hz, and 230/460 V operation. Efficiency is rated as Premium (86.50%), with a service factor of 1.15 and NEMA design code B, suitable for continuous-duty applications.
Yes. The paint-free, stainless steel frame and TEFC enclosure are designed for frequent washdowns and corrosive exposure typical in food, beverage, and pharmaceutical processing lines. The motor carries safety certifications (CSA, CSA EEV, UR) and is engineered for hygienic cleaning regimes without compromising reliability.
The motor carries CSA, CSA EEV, and UR certifications, indicating compliance with recognized safety and electrical standards. These certifications are important for regulatory compliance, insurance requirements, and market access in industrial facilities that mandate validated electrical gear for reliability and safety in critical processes.
Maintenance benefits come from sealed bearings, a paint-free stainless frame, and a robust TEFC design that minimizes corrosion-related downtime. ROI is enhanced by Premium Efficiency helping reduce energy costs, lower cooling and maintenance needs, and longer service intervals, contributing to a lower total cost of ownership over the motor’s life.
