ABB 7BCEWDM3545 Washdown Motor - IE3 Premium
Part Number: 7BCEWDM3545
Quick Summary
ABB washdown motor 7BCEWDM3545 delivers reliable, washdown-ready drive power for food and beverage equipment. In harsh washdown environments, downtime from corrosion, leaks, and failed seals is a persistent risk, and maintenance costs can rise quickly. This motor is designed with a TEFC enclosure and a 56C frame to resist moisture, while maintaining strong performance across 60 Hz operation. It carries IE3 premium efficiency and NEMA Premium certification along with CSA and UR approvals, reinforcing compliance and long-term energy savings. By combining robust construction with industry-standard mounting options, you get faster installation, easier service, and predictable uptime that translates to lower total cost of ownership for your production line.
Product Information
Extended Description
7BCEWDM3545 ABB: Washdown Motor 1 Hp 230 V (CEWDM3545)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,3450RPM,3PH,60HZ,56C,3516M,TEFC
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
CEWDM3545
Certification Agency
CSA | CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
B
Dimension Diagram
35LYT986: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
CEWDM3545
Gross Volume
2110.969 in³
Gross Weight
33 lb
Horsepower Rating UL/CSA
1.000 Hp
IC Class
TEFC
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
1HP,3450RPM,3PH,60HZ,56C,3516M,TEFC,F1,N
Lubrication
For life
Made To Order
No
Medium Description
White Washdown, 1 HP, 3600 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (CEWDM3545)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Motor Frame Suffix
C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
87 %
Product Name
White Washdown
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
33 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
2.8 A | 1.4 A
Rated Efficiency
77 %
Rated Speed
3450 r/min
Replaced Product ID (OLD)
7B35T986Y474G1
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.25
Service Factor Percentage
1.25 %
Shaft Diameter
0.63 in
Short Description
1 HP, 3600 RPM, Frame Size 56C, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101112
Voltage Code
K
Voltage Rating
230 V | 460 V
TEFC enclosure protects windings and bearings in wet, washdown environments, extending motor life. This 56C frame with a C-face drive end flange delivers secure mounting for horizontal, foot-mounted installations in conveyors and pumps. IE3 premium efficiency reduces energy consumption on continuous duty lines, and the rated currents of 2.8 A at 230 V / 1.4 A at 460 V help lower operating costs and heat generation. A three-phase, 60 Hz, 2-pole design with direct-on-line starting provides consistent torque and simple integration with standard drives. The rated speed of 3450 r/min supports reliable belt and pulley configurations, while RoHS compliance and CSA/UR/NEMA Premium certifications ensure regulatory alignment and long-term reliability. Designed for continuous duty, with life-long lubrication and sealed bearings, it reduces maintenance windows and helps keep lines running. Robust mounting options—horizontal orientation, foot mounting, and C-face flange—facilitate fast site installation and interchangeability with existing equipment on production floors. The product’s ambient rating of up to 40 °C and altitude up to 1000 m makes it suitable for typical plant floors, while the 56C frame and steel construction provide durability in demanding environments. Stocked across multiple warehouses at 0 day lead time, this motor is engineered to lower total cost of ownership through dependable performance and easier procurement.
Get a Quick Quote for a ABB 7BCEWDM3545
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEWDM3545?
Enquire Now
FAQs
It uses a C-face drive end flange and a foot-mounted base in a horizontal orientation with a 56C frame, enabling secure attachment to standard bases and direct coupling to conveyors or pumps.
Yes. It features a TEFC enclosure and a White Washdown design, rated for typical plant climates (ambient up to 40 °C, up to 1000 m altitude), with RoHS compliance and sealed bearings for dependable service.
The motor is three-phase, 230/460 V, 60 Hz, 2-pole, rated at 1 HP with rated currents of 2.8 A (230 V) or 1.4 A (460 V). It offers a continuous duty rating, 3450 r/min nominal speed, and a service factor of 1.25.
The motor carries IEC/UL-aligned certification with CSA, CSA EEV, UR, and NEMA Premium, along with IE3 premium efficiency and RoHS compliance for regulatory and environmental requirements.
Ideal for food processing, beverage packaging, and wet-line conveyors, the IE3 efficiency reduces energy costs on continuous-duty lines. The robust TEFC design and rated life minimize maintenance downtime, contributing to lower total cost of ownership over time.
