ABB CEWDM3714T-5 Washdown Motor - IE3 Premium Efficiency
Part Number: 7BCEWDM3714T-5
Quick Summary
Washdown Motor ABB CEWDM3714T-5 delivers reliable, hygienic power for food processing and washdown environments. In harsh production lines, moisture exposure, corrosion risk, and unplanned downtime threaten throughput and maintenance budgets. It carries CSA, CSA EEV, and UR certifications to support global compliance, while IE3 premium efficiency helps cut energy costs. With a TEFC enclosure and a 10 HP rating, it stands up to frequent washdowns, and the 215TC frame with C‑Face mounting simplifies installation across standard equipment. This combination delivers lower total cost of ownership and better sustainability for process automation teams.
Product Information
Extended Description
7BCEWDM3714T-5 ABB: Washdown Motor 10 Hp 575 V (CEWDM3714T-5)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
10HP,1770RPM,3PH,60HZ,215TC,3752M,T
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6307 | Ball
Bearing NDE
6206 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CEWDM3714T-5
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
A
Dimension Diagram
37LYG815: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
215
Frequency (f)
60 Hz
Global Commercial Alias
CEWDM3714T-5
Gross Volume
7561.383 in³
Gross Weight
165 lb
Horsepower Rating UL/CSA
10.000 Hp
IC Class
TEFC
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
10HP,1770RPM,3PH,60HZ,215TC,3752M,TEFC,F
Lubrication
For life
Made To Order
No
Medium Description
White Washdown, 10 HP, 1800 RPM, Frame Size 215Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 575 V, 60 Hz (CEWDM3714T-5)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
215TC
Motor Frame Suffix
TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
10 Hp
Power Factor
85 %
Product Name
White Washdown
Product Net Depth / Length
26.375 in
Product Net Height
17.375 in
Product Net Weight
165 lb
Product Net Width
16.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
9.6 A
Rated Efficiency
91.70 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
1.38 in
Short Description
10 HP, 1800 RPM, Frame Size 215Tc, C-Face, 3 PH, TEFC, 575 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101115
Voltage Code
K
Voltage Rating
575 V
Feature TEFC enclosure provides rugged protection against washdown moisture and dust, reducing corrosion risk and extending service life. Business Impact: lower maintenance intervals, fewer gasket failures, and higher line uptime. Application: food processing lines, beverage packaging, pharmaceutical filling stations. Feature 10 HP, 575 V, 60 Hz, 3-phase design delivers high starting torque and reliable operation on conveyors, pumps, and mixers. Business Impact: enables direct-on-line starts for streamlined drive matching and reduced soft-start requirements. Application: packaging lines and material handling. Feature 215TC frame with C-Face mounting and horizontal orientation simplifies installation, retrofit compatibility, and cabling. Business Impact: faster commissioning and standardized spares across multiple facilities. Application: OEM equipment, pumps, fans, and conveyors. Feature IE3 premium efficiency, Insulation Class F, and a 1.15 service factor support energy efficiency and durable performance under continuous duty. Business Impact: lower energy costs, improved heat management, and extended motor life. Application: continuous washdown operations in beverage, food, and pharma lines. Feature Lubrication for life, 1.38 in shaft diameter, and 1770 rpm rated speed deliver reliable, low-maintenance operation. Business Impact: reduced maintenance intervals and stable torque delivery for drive applications. Application: conveyors and mixer duties in hygienic environments. Certifications CSA, CSA EEV, UR alongside stock availability and zero lead time further de-risk project timelines. Business Impact: faster procurement, broad regional coverage, and quick commissioning for capital projects. Application: global manufacturing facilities and multi-site operations.
Get a Quick Quote for a ABB 7BCEWDM3714T-5
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCEWDM3714T-5?
Enquire Now
FAQs
The CEWDM3714T-5 uses a 215TC frame with C-Face mounting for straightforward alignment and bolting to standard bases. It is a 3‑phase, 575 V motor designed for direct-on-line starts at 60 Hz, simplifying drive selection and installation in existing equipment without custom adapters. Ensure compatible base adapters and electrical harnesses are used to maintain washdown integrity.
This motor is certified under CSA, CSA EEV, and UR, providing North American and global compliance assurance for industrial equipment in hygienic and safety-critical settings. Certification support helps accelerate approvals for food, beverage, and pharmaceutical facilities and reduces vendor risk when validating supplier Quality and Safety standards.
Yes. The motor features a TEFC enclosure and a design optimized for washdown conditions, with a service factor of 1.15 and insulation class F. Combined with IE3 efficiency, it supports continuous operation, durable heat management, and lower energy costs on long production runs in hygienic facilities.
Key specs include 10 HP output, 575 V voltage, 60 Hz frequency, 1770 r/min rated speed, 9.6 A rated current, and 85% power factor. The motor uses a 215TC frame, TEFC enclosure, and 3‑phase design, with a service factor of 1.15 and 1.38 in shaft diameter. These specs ensure robust torque, reliable operation, and compatibility with standard drive systems.
The CEWDM3714T-5 is stocked at multiple warehouses and shows a 0 day lead time, reflecting immediate availability for urgent projects. This makes it well-suited for multi-site rollouts and quick replacements in maintenance-driven environments, minimizing downtime and accelerating project timelines.
