ABB 7BCHC445A Farm Duty Motor - 0.75 HP 60 Hz TEAO
Part Number: 7BCHC445A
Quick Summary
The Farm Duty Motor 0.75 HP from ABB provides reliable single‑phase power for agricultural and environmental cooling fans. Operators frequently contend with downtime, mismatched parts, and sourcing delays that inflate maintenance costs. Certified RoHS, CSA/UR, and NEMA‑compliant design supports safe, durable operation in harsh environments. With a TEAO enclosure, 56YZ frame, and 1‑phase 60 Hz capability, installation is straightforward and scalable, reducing total cost of ownership. This motor is designed for direct‑drive fans and general purpose industrial equipment, enabling quick replacements and a lean spare parts footprint.
Product Information
Extended Description
7BCHC445A ABB: Farm Duty Motor 0.75 Hp 115 V (CHC445A)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75HP,1700RPM,1PH,60HZ,56YZ,3428C,T
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CHC445A
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
34LYM244: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
Resilient Mount
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
CHC445A
Gross Volume
3496.049 inÂł
Gross Weight
35 lb
Horsepower Rating UL/CSA
0.750 Hp
IC Class
TEAO
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
B
Invoice Description
.75HP,1700RPM,1PH,60HZ,56YZ,3428C,TEAO,F
Lubrication
Regreasable
Made To Order
No
Medium Description
Direct Drive Fan, 0.75 HP, 1800 RPM, Frame Size 56Yz, ResilientMount Mounting, 1 Phase, TEAO Enclosure, 115/230 V, 60 Hz (CHC445A)
Minimum Order Quantity
1 piece
Motor Base Type
Resilient
Motor Frame Size
56YZ
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.75 Hp
Power Factor
92 %
Product Name
Direct Drive Fan
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
35 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
7.4 A | 3.7 A
Rated Efficiency
74 %
Rated Speed
1700 r/min
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.63 in
Short Description
0.75 HP, 1800 RPM, Frame Size 56Yz, ResilientMount, 1 PH, TEAO, 115/230 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101105
Voltage Code
F
Voltage Rating
115 V | 230 V
Feature: The motor operates on a simple single‑phase 115/230 V supply at 60 Hz, delivering 0.75 HP. Business Impact: This dual‑voltage capability reduces panel design complexity and inventory for regional sites while keeping installation straightforward. Application: Suitable for direct‑drive fans, small conveyors, and process equipment in agriculture, HVAC, and industrial environments. Feature: TEAO enclosure and 56YZ frame maximize airflow and durability in harsh environments. Business Impact: Improves reliability in heat‑soaked spaces and mitigates enclosure overheating, while maintaining compatibility with standard mounting patterns for retrofit projects. Application: Ideal for direct‑drive fans and compact industrial machinery in pubs, greenhouses, and processing lines. Feature: Resilient mounting and horizontal orientation minimize vibration and simplify alignment. Business Impact: Reduces operator maintenance, belt wear, and machine downtime, delivering longer service intervals. Application: Suited for horizontal installations in space‑constrained equipment and retrofits in existing lines. Feature: Regreasable bearings (6203) and direct‑on‑line starting support easy maintenance and predictable life cycles. Business Impact: Lower total cost of ownership through extended bearing life and simpler lubrication routines. Application: Effective in remote plants and service‑heavy environments where downtime is costly. Feature: RoHS compliance, CSA/UR certification, and NEMA compatibility provide procurement confidence and regulatory alignment. Business Impact: Streamlines vendor qualification, reduces risk, and accelerates project approvals. Application: Suitable for regulated industries and multi‑site deployments with standardized specs.
Get a Quick Quote for a ABB 7BCHC445A
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCHC445A?
Enquire Now
FAQs
Plan for horizontal mounting in an F1 orientation using the resilient base. The 56YZ frame and TEAO enclosure provide a compact footprint with easy retrofitting into existing equipment. The motor is designed for direct drive and simple wiring, minimizing cabinet space and wiring complexity while maintaining vibration control and alignment stability.
Key specs include 0.75 HP output, 1700 r/min nominal speed, 1 phase operation at 115/230 V, and a service factor of 1.15. The motor supports direct on line starting and a power factor around 92%, making it well suited for small fans, conveyors, and process cooling in light industrial settings.
Yes. The CHC445A series is RoHS compliant and carries CSA/UR certification, with NEMA compatibility. These certifications support regulatory compliance in North America and simplify supplier qualification for regulated industries, while ensuring safe operation in harsh environments from greenhouse to factory floors.
The motor uses regreasable bearings (6203, ball). Follow a scheduled lubrication interval per maintenance programs to optimize bearing life. This approach reduces unexpected downtime, extends service life, and lowers long‑term replacement costs, especially in remote or high‑heat installations where lubrication access may be limited.
ROI improves through reduced downtime, easier installation, and lower spare parts inventory thanks to dual voltage operation, a TEAO enclosure, and a resilient mount. The combination of a 1.15 service factor and high reliability translates to fewer maintenance events, longer intervals between replacements, and faster project payback in continuous‑duty farm and industrial cooling applications.
