ABB 7BCL3507 General Purpose Motor - CSA UR
Part Number: 7BCL3507
Quick Summary
ABB 7BCL3507 general purpose motor is designed for reliable, cost‑effective operation in light industrial equipment. This 0.75 HP, single‑phase motor supports 115 V or 230 V operation at 60 Hz, with a TEFC enclosure and a 56C frame. A common pain point is stock availability and predictable lead times; this model ships with zero days lead time and is stocked at multiple warehouses. The unit carries CSA and UR recognition with a NEMA design heritage, helping streamline regulatory compliance. By combining straightforward installation, robust construction, and readily available spare parts, it delivers predictable performance and a lower total cost of ownership. For OEMs and service providers, the ABB 7BCL3507 translates to faster uptime and easier procurement.
Product Information
Extended Description
7BCL3507 ABB: General Purpose Motor 0.75 Hp 115 V (CL3507)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75HP,1725RPM,1PH,60HZ,56C,3428LC,T
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6203 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
CL3507
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
N
Dimension Diagram
34LYG451: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
CL3507
Gross Volume
2110.969 in³
Gross Weight
34 lb
Horsepower Rating UL/CSA
0.750 Hp
IC Class
TEFC
IDEA Granular Category Code (IGCC)
1329 >> Single phase motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
.75HP,1725RPM,1PH,60HZ,56C,3428LC,TEFC,F
Lubrication
Regreasable
Made To Order
No
Medium Description
General Purpose 1PH Enclosed, 0.75 HP, 1800 RPM, Frame Size 56C, C-Face Mounting, 1 Phase, TEFC Enclosure, 115/230 V, 60 Hz (CL3507)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Motor Frame Suffix
C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.75 Hp
Power Factor
78 %
Product Name
General Purpose 1PH Enclosed
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
34 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
8.4 A | 5.4 A | 4.2 A
Rated Efficiency
72 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.25
Service Factor Percentage
1.25 %
Shaft Diameter
0.63 in
Short Description
0.75 HP, 1800 RPM, Frame Size 56C, C-Face, 1 PH, TEFC, 115/230 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101116
Voltage Code
J
Voltage Rating
115 V | 230 V
Feature → Business Impact → Application: 0.75 HP, 1725 rpm, 1‑phase, 60 Hz operation provides efficient power for small conveyors, pumps, and fans. This reduces energy use during steady running while maintaining performance for continuous duty tasks. Application: Light industrial lines and OEM installations benefit from predictable starting torque, simple wiring, and compatibility with standard control gear. Feature → Business Impact → Application: TEFC enclosure resists dust and moisture ingress, improving uptime in workshop and factory environments; ideal for dusty or humid spaces and retrofit projects. Application: General purpose machinery in manufacturing, packaging, and material handling benefits from a robust, maintenance‑friendly footprint. Feature → Business Impact → Application: 56C frame with C‑Face mounting and foot mounting simplifies retrofits and new builds, reducing installation time and costs across assemblies, conveyors, and fans.
Get a Quick Quote for a ABB 7BCL3507
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BCL3507?
Enquire Now
FAQs
Yes. The ABB 7BCL3507 is a general purpose single‑phase motor designed for 115 V or 230 V operation at 60 Hz. It features a TEFC enclosure and a 56C frame, making it suitable for compact, shop-floor equipment and light industrial machines. Ensure proper voltage selection and use suitable starters per your control scheme.
Key specs include a 56C frame, 0.63 in shaft diameter, 1725 rpm (Synchronous 1800 rpm), foot mounting with C‑Face drive end, and a TEFC enclosure. It uses ball bearings (6203) and regreasable lubrication, with a 34 lb weight and compact dimensions roughly 16.5 in long, 11.5 in wide, and 11.125 in high.
Certifications for the ABB 7BCL3507 include CSA and UR recognition, with a NEMA design basis. The unit is built in the United States and stocked across multiple warehouses, supporting regulatory compliance and rapid procurement in North American facilities.
Ideal for general purpose drives in light manufacturing, conveyors, pumps, and fans. The 0.75 HP, 56C frame and 1‑phase, 60 Hz rating support straightforward integration with standard controls and existing equipment, delivering reliable performance in compact footprints.
Maintenance is straightforward due to regreasable bearings and a TEFC enclosure that resists dust and moisture. With a service factor of 1.25 and continuous duty, it supports long run times between service. Stocked availability and 0‑day lead times help minimize downtime and optimize ROI for OEMs and service providers.
