ABB 7BD2305 DC Wound Field Fractional - CSA/UR
Part Number: 7BD2305
Quick Summary
ABB 7BD2305 DC Wound Field Fractional motor drives compact, reliable performance for small machines and conveyors. This model helps shorten downtime by offering immediate availability from US and global stock, addressing procurement delays that hinder project timelines. It carries CSA and UR certifications, RoHS compliance, and a NEMA-aligned TEFC enclosure for rugged industrial service. With a 1.5 HP rating at 1750 rpm and 230 V operation, it fits standard drive trains without custom hardware. Designed for continuous duty and straightforward maintenance, the motor ships from multiple stocking locations, including US warehouses, supporting faster deployments and lower total cost of ownership across inline packaging, sorting, and light manufacturing lines.
Product Information
Extended Description
7BD2305 ABB: DC Wound Field Fractional Comp 1.5 Hp (D2305)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5HP,1750RPM,DC,184,3636D,TEFC,F1
Ambient Temperature
40 °C
Armature Current
5.8 A
Armature Inertia
30.34 ft·lbf
Armature Voltage
230 V
Base Speed
1750 r/min
Bearing
6206, Sealed Bearing
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
D2305
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
36LY5313
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Enclosure Type
TEFC
Field Voltage
230 V
Frame Material
Steel
Frame Size
184
Global Commercial Alias
D2305
Gross Volume
3590.443 inÂł
Gross Weight
82 lb
Horsepower Rating UL/CSA
1.500 Hp
Insulation Class
F
Invoice Description
1.5HP,1750RPM,DC,184,3636D,TEFC,F1
Made To Order
No
Medium Description
DC Wound Field Fractional Comp, 1.5 HP, Frame Size 184, 0 Phase, TEFC Enclosure, (D2305)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184
Mounting Orientation
Horizontal
Number of Phases
0
Order Multiple
1 piece
Output Power
1.5 Hp
Product Name
DC Wound Field Fractional Comp
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
82 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Speed
1750 r/min
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.88 in
Short Description
1.5 HP, Frame Size 184, 0 PH, TEFC,
Standards
NEMA
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Type of Duty
Continuous
Feature: DC wound field fractional design provides precise torque control and smooth startup, reducing belt wear and peak current. Business Impact: Improves line uptime and extends motor life in low- to mid-torque applications. Application: Suitable for compact conveyors and small automation loops where space is at a premium. Feature: Frame size 184 with foot mounting offers a compact footprint and easy installation. Business Impact: Enables versatile mounting in tight enclosures and on standard baseplates, lowering installation time. Application: Small machinery, tooling stations, and packaging printers. Feature: 230 V operation paired with 1.5 HP output delivers reliable performance for mid-sized loads. Business Impact: Delivers consistent speed and torque with familiar power infrastructure, reducing the need for transformers or adapters. Application: OEM equipment and line conveyors. Feature: TEFC enclosure and 40 °C ambient tolerance enhance protection against dust and heat. Business Impact: Supports compliant operation in typical factory floors and harsh environments, decreasing maintenance cycles. Application: Food processing, material handling, and automation cells. Feature: RoHS compliant and CSA/UR certification ensure regulatory alignment. Business Impact: Eases procurement and compliance audits, enabling faster certification for OEMs. Application: Industrial automation integrations and equipment upgrades. Feature: Stocked at multiple locations with 0 day lead time provides rapid deployment. Business Impact: Minimizes project delays and reduces carrying costs for safety stock. Application: Urgent retrofits, spares management, and just-in-time manufacturing environments.
