ABB 7BDM3542 Motor - TEFC, 230/460V, 0.75HP NEMA B
Part Number: 7BDM3542
Quick Summary
ABB 7BDM3542 motor provides reliable 0.75 HP, 230V three-phase power for demanding conveyor and pump installations. When downtime is costly, stock availability and installation simplicity matter, and this unit ships from multiple warehouses to minimize wait times. It features a TEFC enclosure, Class F insulation, and a NEMA design B profile, aligning with common industrial compliance practices. With frame size 56 and rugged bearings, it delivers dependable torque and predictable performance for continuous-duty environments, helping engineers reduce maintenance overhead and extend asset life in harsh conditions.
Product Information
Extended Description
7BDM3542 ABB: Severe Duty Motor 0.75 Hp 230 V (DM3542)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75HP,1725RPM,3PH,60HZ,56,3428M,TEF
Ambient Temperature
40 °C
Bearing
6203, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
DM3542
Certification Agency
CCSA US | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
34LYM812: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
DM3542
Gross Volume
2110.969 in³
Gross Weight
30 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
.75HP,1725RPM,3PH,60HZ,56,3428M,TEFC,F1
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
Dirty Duty Autophoretic, 0.75 HP, 1800 RPM, Frame Size 56, Standard Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (DM3542)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.75 Hp
Power Factor
68 %
Product Name
Dirty Duty Autophoretic
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
30 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
2.8 A | 1.4 A
Rated Efficiency
74 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.25
Shaft Diameter
0.63 in
Short Description
0.75 HP, 1800 RPM, Frame Size 56, Standard, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: TEFC enclosure protects internal windings from dirt, moisture, and contaminants, increasing motor life in dirty-duty environments and reducing unplanned downtime in material handling lines; this translates to lower maintenance costs and higher overall equipment efficiency (OEE) for conveyors. Feature → 56 frame, foot-mounted base → Easier installation and standardized mounting across fleets, enabling rapid replacement in refineries, mills, and packaging lines; applicable to horizontal F1 mounting in existing footprints. Feature → 3-phase, 60 Hz, 230/460 V → Flexible voltage handling supports dual-supply facilities and spares strategy, minimizing re-wiring work and inventory diversity for pumps and fans. Feature → 0.75 HP, 1725 RPM, NEMA B → Predictable torque and safe startup characteristics, suitable for continuous-duty duty cycles in HVAC, bottling, and washing systems. Feature → Class F insulation, 40 °C ambient → Thermal resilience for extended service life in challenging environments, reducing rework during seasonal peaks. Feature → Stocked At Warehouses (0 day lead time) → Immediate availability lowers downtime risk and accelerates project schedules in automation retrofits and OEM builds.
