ABB 7BEBM3615T-S Brake - 5HP, 230V TEFC, CE/CSA
Part Number: 7BEBM3615T-S
Quick Summary
7BEBM3615T-S brake provides precise stopping for 3-phase motors in industrial conveyors and packaging lines. In busy plants, braking stalls and downtime due to inconsistent stops can cause product damage and safety concerns. Certified CE, CSA, and UR (with WEEE compliance) ensure global acceptance and regulatory confidence. Designed for 60 Hz operation, 230/460 V drives and a 184T frame with TEFC enclosure, this short-series brake integrates with standard motor bases and horizontal, foot-mounted configurations. By delivering reliable engagement and reduced wear on downstream components, it supports measurable ROI through lower maintenance needs and faster changeovers.
Product Information
Extended Description
7BEBM3615T-S ABB: Short Series Brake 5 Hp 230 V (EBM3615T-S)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1750RPM,3PH,60HZ,184T,3642M,TEF
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6206
Brake Present
Yes
Brand / Label
Baldor-Reliance
Catalog Number
EBM3615T-S
Certification Agency
CE | CSA | CSA EEV | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
36LYM813: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
184
Frequency (f)
60 Hz
Global Commercial Alias
EBM3615T-S
Gross Volume
7192.91 in³
Gross Weight
106 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
5HP,1750RPM,3PH,60HZ,184T,3642M,TEFC,F1
Made To Order
No
Medium Description
Short Series Brake, 5 HP, 1800 RPM, Frame Size 184T, Standard Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (EBM3615T-S)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
78 %
Product Name
Short Series Brake
Product Net Depth / Length
26.625 in
Product Net Height
16.25 in
Product Net Weight
106 lb
Product Net Width
16.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
13.4 A | 6.7 A
Rated Efficiency
89.50 %
Rated Speed
1750 r/min
Replaced Product ID (OLD)
7B36M813S268G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Short Description
5 HP, 1800 RPM, Frame Size 184T, Standard, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
The Short Series Brake design packs 5 HP braking into a compact TEFC package, reducing enclosure footprint and simplifying installation on foot-mounted motors in space-constrained panels. This translates to lower installation costs and quicker retrofit in conveyors and packaging lines, with predictable stopping performance that minimizes product damage. The brake’s high efficiency (up to 89.5%) and service factor of 1.15 deliver reliable performance under continuous duty, improving line uptime and reducing wear on gears and belts. With 60 Hz, 230/460 V compatibility and a robust 184T frame, it fits standard motor bases and allows straightforward on-site maintenance, while Direct On Line starting simplifies drive integration. Certifications (CE, CSA, UR, WEEE) provide compliance confidence and regional applicability for global projects. Stocked at multiple warehouses supports faster procurement and reduced lead times, boosting project velocity.
Get a Quick Quote for a ABB 7BEBM3615T-S
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BEBM3615T-S?
Enquire Now
FAQs
Yes. The 7BEBM3615T-S is designed for 184T frame motors, 60 Hz operation, and supports 230/460 V three-phase power with a TEFC enclosure, making it suitable for standard conveyors and packaging line applications.
The unit lists Rated Current as 13.4 A / 6.7 A and Rated Efficiency at 89.5%, supporting reliable performance with energy-conscious operation in continuous-duty environments.
Yes. The ABB Short Series Brake supports direct-on-line starting, enabling straightforward integration with common drives and minimizing control hardware while delivering rapid, controlled stops.
The brake is CE, CSA, CSA EEV, UR certified and WEEE compliant, ensuring global applicability and compliance with safety, environmental, and electrical standards.
With a robust 5 HP braking capability, TEFC enclosure, and 184T frame, the unit reduces brake-related downtime and wear on downstream components. Stock availability across warehouses accelerates procurement, while warranty terms support long-term maintenance planning and cost savings.
