ABB 7BEBNM3554T-D D-Series Brake - CE CSA UR
Part Number: 7BEBNM3554T-D
Quick Summary
D-Series Brake is a compact braking solution for 1.5 HP, 230 V three-phase motors used in conveyors, packaging lines, and machine tools. When stop accuracy and uptime matter, engineers rely on a proven, easy-to-integrate brake that works with standard ABB drive systems. The product is certified for CE, CSA, CSA EEV and UR, supporting global compliance, while its 60 Hz rating and TENV enclosure ensure reliable performance in typical factory environments. With a 145Ty frame and a foot-mounted, horizontal F3 mounting, installation is straightforward, reducing wiring and commissioning time. This combination delivers dependable braking, improved cycle times, and predictable maintenance costs for maintenance teams and procurement leaders.
Product Information
Extended Description
7BEBNM3554T-D ABB: D-Series Brake 1.5 Hp 230 V (EBNM3554T-D)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5/1.1KWHP,1770 1/MINRPM,3PH,60HZ,
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
Yes
Brand / Label
Baldor-Reliance
Catalog Number
EBNM3554T-D
Certification Agency
CE | CSA | CSA EEV | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYX164: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
EBNM3554T-D
Gross Volume
3590.443 inÂł
Gross Weight
62 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
H
Invoice Description
1.5/1.1KWHP,1770 1/MINRPM,3PH,60HZ,145TY
Made To Order
No
Medium Description
D-Series Brake, 1.5 HP, 1800 RPM, Frame Size 145Ty, Standard Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (EBNM3554T-D)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
145TY
Mounting Orientation
Horizontal
Mounting Position
F3
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1.5 Hp
Power Factor
72 %
Product Name
D-Series Brake
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
62 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.6 A | 2.3 A
Rated Efficiency
86.50 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Short Description
1.5 HP, 1800 RPM, Frame Size 145Ty, Standard, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature: Integrated D-Series Brake for 1.5 HP, 230 V, three-phase systems. Business Impact: Enables precise stopping and holding, reducing mechanical wear and cycle time variability. Application: Ideal for conveyors and machine-tools where controlled deceleration is critical. The result is improved line throughput and longer drive life. Long-tail keywords such as D-Series brake, 1.5 HP brake, and 230 V three-phase motors are integrated naturally to support search relevance. Feature: Frame Size 145Ty with Foot Mounted horizontal mounting (F3). Business Impact: Simplifies installation, minimizes misalignment risk, and reduces mounting footprint in compact equipment. Application: Suitable for retrofit or new builds with limited space. Feature: Voltage Range 230/460 V and Rated Current 4.6 A | 2.3 A. Business Impact: Flexible supply compatibility and scalable control without extra wiring complexity. Application: Works with standard 3-phase power and ABB controls to achieve reliable stop/start sequences. Feature: Enclosure Type TENV, Insulation Class H, and Synchronous Speed 1800 r/min. Business Impact: Enables operation in warmer environments with high insulation performance and predictable motor synchronization. Application: Industrial environments requiring robust protection and stable performance. Feature: NEMA Design Code B, Service Factor 1.15, Efficiency 86.50%. Business Impact: Improves reliability and efficiency, reducing energy consumption and maintenance costs over the motor’s life. Application: Continuous-duty applications with frequent start/stop cycles, such as packaging lines and automated feeders.
