ABB 7BECP49404T-5 LV Severe Duty Motors - Premium Efficiency
Part Number: 7BECP49404T-5
Quick Summary
ABB 7BECP49404T-5 LV Severe Duty Motors deliver rugged, high-power performance for heavy industrial applications such as pumps, conveyors, and milling lines. Operators often face downtime and energy waste when motors underperform in harsh environments, driving maintenance costs and missed production targets. This motor carries CSA EEV certification, NEMA Premium Efficiency, and a TEFC enclosure, strengthening compliance and reliability across US plants. With a 400 HP rating at 575 V, it offers a robust combination of torque, efficiency, and installation versatility for line-side upgrades. In demanding facilities, this motor reduces energy use, improves uptime, and simplifies spare-part provisioning.
Product Information
Extended Description
7BECP49404T-5 ABB: Severe Duty Motor 400 Hp 575 V (ECP49404T-5)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
400HP,1785RPM,3PH,60HZ,L449T,TEFC,F
Ambient Temperature
40 °C
Bearing
6318, Ball
Bearing NDE
6318
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ECP49404T-5
Certification Agency
CSA EEV
Country of Origin
United States (US)
Customs Tariff Number
85015381
Drive End Flange Type
Standard
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Iron
Frame Size
Undefined
Global Commercial Alias
ECP49404T-5
Gross Weight
3702 lb
Insulation Class
F
Invoice Description
400HP,1785RPM,3PH,60HZ,L449T,TEFC,F1
Made To Order
No
Medium Description
Frame Size L449T, Standard Mounting, 3 Phase, TEFC Enclosure, (ECP49404T-5)
Minimum Order Quantity
1 piece
Motor Base Type
Rigid
Motor Frame Size
L449T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
400 Hp
Power Factor
88 %
Product Name
LV Severe Duty Motors
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
3702 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
356 A
Rated Efficiency
96.20 %
Rated Speed
1785 r/min
Replaced Product ID (OLD)
7BA44-8455-5532
Selling Unit of Measure
piece
Service Factor
1.15
Short Description
Frame Size L449T, Standard, 3 PH, TEFC,
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
575 V
Feature: 400 HP, 575 V, 3-phase, 4-pole, 1785 r/min with a frame size of L449T. Business Impact: Delivers substantial torque while matching common 575 V industrial power systems, enabling smooth integration with existing drives and controls. Application: Ideal for heavy load drives such as conveyors, mills, and large pumps. Feature: TEFC enclosure. Business Impact: Provides robust protection against dust, moisture, and gritty plant environments, reducing maintenance cycles and preventing winding damage. Application: Suitable for dusty manufacturing floors, mining facilities, and chemical processing plants. Feature: Premium Efficiency (96.20%) and NEMA Design B. Business Impact: Lower operating costs through energy savings and improved power factor, delivering rapid ROI in continuous-duty operations. Application: Beneficial for long-running fans, pumps, and material handling lines. Feature: Frame L449T, Horizontal mounting, Rigid motor base. Business Impact: Simplifies installation, alignment, and retrofit with standard mounting footprints, cutting commissioning time. Application: Retrofit projects and new installations across plant floors with limited clearance. Feature: Rated Current 356 A at 575 V and Direct On Line starting. Business Impact: Clear electrical design parameters support protective coordination and straightforward electrical wiring. Application: Heavy-load startups in packaging lines, water treatment, and mineral processing. Feature: Ambient 40 °C rating and CSA EEV/NEMA-compliant construction. Business Impact: Ensures reliable performance in hot plants while meeting regulatory and standards requirements. Application: US-based manufacturing facilities with elevated ambient temperatures.
