ABB ECS101M0H7FB4 ECM Motor - 7.5 HP 60 Hz IE5 TEFC
Part Number: 7BECS101M0H7FB4
Quick Summary
ABB ECS101M0H7FB4 ECM Motor delivers high-efficiency, reliable drive for industrial fans, pumps, and machine tools in high-demand environments. Many facilities struggle with energy waste, downtime, and mismatched drive platforms when upgrading from legacy motors. This model aligns with NEMA standards and carries CULUS and WEEE certifications for safe operation and end-of-life compliance. With 60 Hz operation, 7.5 HP output, and 230/460 V dual voltage support, it enables consistent performance across varied process conditions while reducing total cost of ownership. The result is a scalable solution that supports uptime, energy efficiency, and predictable procurement for industrial automation projects.
Product Information
Extended Description
7BECS101M0H7FB4 ABB: ECM 7.5 Hp 230 V (ECS101M0H7FB4)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
7.5HP,1800RPM,3PH,60HZ,213TC,TEFC,N
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6307
Bearing NDE
6206
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ECS101M0H7FB4
Certification Agency
CULUS | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
C-Face
Efficiency Level
IE5
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
213
Frequency (f)
60 Hz
Global Commercial Alias
ECS101M0H7FB4
Gross Volume
7561.383 in³
Gross Weight
167 lb
Insulation Class
F
Invoice Description
7.5HP,1800RPM,3PH,60HZ,213TC,TEFC,N
Made To Order
No
Medium Description
ECM, 7.5 HP, 1800 RPM, Frame Size 213Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (ECS101M0H7FB4)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
213TC
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
7.5 Hp
Power Factor
92 %
Product Name
ECM
Product Net Depth / Length
26.375 in
Product Net Height
17.375 in
Product Net Weight
167 lb
Product Net Width
16.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
8.9 A
Rated Efficiency
94 %
Rated Speed
1800 r/min
Selling Unit of Measure
piece
Service Factor
1.50
Shaft Diameter
1.38 in
Shaft Grounding
Shaft Grounding
Short Description
7.5 HP, 1800 RPM, Frame Size 213Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The ECS101M0H7FB4 motor delivers IE5 efficiency (94%) and a PF of 92%, reducing energy costs during continuous operation in fans, pumps, and conveyors. This translates to lower running expenses and shorter payback periods on new installations or upgrades to your HVAC, process cooling, or material handling systems. In practice, users experience steadier load profiles and measurable improvements in overall equipment effectiveness (OEE) when paired with appropriate drive controls and closed-loop feedback. The 7.5 HP, 1800 r/min rating at 60 Hz suits 4-pole designs for stable speed control across high-demand processes, reinforcing reliability in industrial automation setups. Compatibility with 230/460 V allows seamless integration with global plant footprints and reduces spare-part complexity, while direct-on-line starting minimizes startup hardware costs. The TEFC enclosure and 213TC frame size simplify installation and reduce environmental risk in factory floors, enabling quick retrofit or new-build deployments. With a foot-mounted, horizontal orientation and C-Face drive end flange, installation becomes straightforward and aligns with common mechanical layouts found in packaging, material handling, and process industries. Stocked at multiple warehouses with a 0-day lead time further lowers procurement risk and ensures project timelines stay on track. Industry context shows that dual-voltage, high-efficiency motors like this reduce energy consumption in continuous-duty drives and improve lifecycle cost, especially in facilities pursuing LEED or energy-performance targets. This makes the ECS101M0H7FB4 a robust choice for OEMs and industrial site engineers seeking reliable, compliant, and readily available gear for demanding operations.
