ABB ECS101T2K1P5DF4 ECM IMD - 1.5kW, 230V IE5
Part Number: 7BECS101T2K1P5DF4
Quick Summary
ABB ECM IMD motor is a high-efficiency drive solution designed for 1.5 kW, 230 V applications in conveyors, pumps, and processing lines. This unit addresses common downtime and compatibility challenges by offering direct-fit mounting, a TEFC enclosure, and global certification, enabling reliable operation in demanding environments. With CE, UKCA, and UL/CUL certifications, plus WEEE compliance, it supports safe, compliant operation across multiple regions. The combination of IE5 efficiency and robust build translates to measurable energy savings and lower total cost of ownership. For engineers and procurement teams, this motor delivers predictable performance, simplified sourcing, and a ready-to-install option for standard industrial drives.
Product Information
Extended Description
7BECS101T2K1P5DF4 ABB: ECM IMD 1.5 kW 230 V (ECS101T2K1P5DF4)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5KW,1500RPM,3PH,50HZ,D90S,3524B,T
Ambient Temperature
40 °C
Base Speed
1500 r/min
Bearing
6205
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
ECS101T2K1P5DF4
Certification Agency
CE | CULUS | UKCA | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE5
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Global Commercial Alias
ECS101T2K1P5DF4
Gross Weight
42 lb
Insulation Class
F
Invoice Description
1.5KW,1500RPM,3PH,50HZ,D90S,3524B,TEFC,B
Made To Order
No
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
D90S
Mounting Orientation
Horizontal
Mounting Position
B3
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1.5 kW
Power Factor
93 %
Product Name
ECM IMD
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
42 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.4 A
Rated Efficiency
90.6 %
Rated Speed
1500 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.95 in
Shaft Grounding
Shaft Grounding
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States
Synchronous Speed (vsyn)
1500 r/min
Type of Duty
Continuous
Voltage Rating
230 V
Feature → Business Impact → Application: The 1.5 kW, 230 V 3-phase ECM IMD motor delivers high efficiency (IE5) which reduces energy costs in continuous-duty applications such as conveyors and pumps. This translates to lower operating costs and improved sustainability metrics on site. Application: Use in automated assembly lines or material handling where consistent torque and efficiency drive overall productivity. Feature → Business Impact → Application: TEFC enclosure provides dust, moisture, and contaminant protection in harsh industrial environments. This minimizes maintenance downtime and extends service life in factories and processing plants. Application: Ideal for food and beverage processing, packaging, and automotive assembly where enclosure integrity is critical. Feature → Business Impact → Application: Foot-mounted, B3 mounting orientation with flexible installation options simplifies retrofits and retrofits in existing frames. Application: Suitable for retrofit projects where space is constrained and performance must match legacy motors without rewiring. Feature → Business Impact → Application: 4-pole design with 1500 r/min base speed ensures stable operation and predictable speed control with standard VFDs. Application: Common in pumping and fan applications requiring steady, maintenance-friendly performance. Feature → Business Impact → Application: CE | UKCA | UL/CUL | WEEE certifications provide global compliance assurance, enabling cross-border sourcing and reducing risk in regulated markets. Application: Essential for international projects, municipal deployments, and equipment catalogs targeting global customers. Feature → Business Impact → Application: 230 V operation with low starting current and Direct-On-Line (DOL) starting capability improves startup reliability. Application: Suitable for line-start in packaging lines and conveyors where immediate torque is needed without complex soft-starts. Feature → Business Impact → Application: Robust mechanical construction with steel frame and 40 °C ambient tolerance supports long service life in factory floors. Application: Heavy-duty material handling, press lines, and extrusion processes where reliability is critical.
