ABB ECS101T3K0P8DD4 ECM IMD - IE5 Efficiency 380V
Part Number: 7BECS101T3K0P8DD4
Quick Summary
ABB ECS101T3K0P8DD4 ECM IMD is a 0.75 kW, 380 V three-phase motor ideal for continuous-duty drives in conveyors, pumps, and processing equipment. It addresses the common pain points of energy waste, heat buildup, and downtime caused by mismatched drives in industrial lines. This motor carries CE, UKCA, and WEEE certifications, with UL/CUL US compatibility, providing regulatory assurance across international installations. Its IE5 efficiency and robust TEFC enclosure translate to lower operating costs, longer service life, and easier integration into existing ABB Baldor-Reliance heritage systems. For procurement teams, the combination of availability, performance, and reliability supports faster ROI and more predictable maintenance planning.
Product Information
Extended Description
7BECS101T3K0P8DD4 ABB: ECM IMD 0.75 kW 380 V (ECS101T3K0P8DD4)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75KW,1500RPM,3PH,50HZ,D90D,3516B,T
Ambient Temperature
40 °C
Base Speed
1500 r/min
Bearing
6205
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
ECS101T3K0P8DD4
Certification Agency
CE | CULUS | UKCA | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015100
Drive End Flange Type
D-Flange
Efficiency Level
IE5
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Global Commercial Alias
ECS101T3K0P8DD4
Gross Weight
47 lb
Insulation Class
F
Invoice Description
.75KW,1500RPM,3PH,50HZ,D90D,3516B,TEFC,B
Made To Order
No
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
D90D
Mounting Orientation
Horizontal
Mounting Position
B35
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
0.75 kW
Power Factor
97 %
Product Name
ECM IMD
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
47 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.4 A
Rated Efficiency
89.2 %
Rated Speed
1500 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.95 in
Shaft Grounding
Shaft Grounding
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
Menden, Germany | China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min
Type of Duty
Continuous
Voltage Rating
380 V
Feature → Business Impact → Application: The IE5 efficiency rating paired with a 0.75 kW output minimizes energy consumption and heat generation, reducing cooling requirements and extending bearing life in high-duty cycles. This translates to lower total cost of ownership and improved machine reliability for conveyors, pumps, and processing lines. Application: factories seeking energy cost containment and longer motor life will benefit from this efficient drive solution. Feature → Business Impact → Application: TEFC enclosure on a 380 V three-phase frame protects windings from dust, moisture, and contaminants, lowering maintenance costs and downtime. This enhances uptime in harsh factory environments and supports long-run operation for material handling and process equipment. Application: production lines that operate in challenging ambient conditions will find rugged performance with minimal service interruptions. Feature → Business Impact → Application: Flexible mounting options (D-Flange, horizontal B35 with a footless base) simplify retrofits and machine integrations, cutting install time and reducing alignment risk. Application: retrofits on existing lines, gear-driven conveyors, and pump assemblies benefit from quick, precise installations. Feature → Business Impact → Application: Stocked at multiple warehouses with 0 day lead time and no Made-To-Order requirement improve project planning and spare-part availability. Application: global manufacturing deployments and maintenance programs gain faster deployment and reliable parts supply. Feature → Business Impact → Application: 4-pole design with direct-on-line starting and 1500 r/min synchronous speed delivers robust torque and predictable performance for continuous processes. Application: use in continuous-duty drives like fans, mixers, and extrusion equipment where consistent RPM and torque are critical.
