ABB 7BECTM2333T-G-AO Chiller/Cooling Tower - NEMA Premium
Part Number: 7BECTM2333T-G-AO
Quick Summary
ABB 7BECTM2333T-G-AO is a high-efficiency chiller/cooling tower designed for commercial and industrial cooling applications. This unit helps facilities achieve reliable process cooling while minimizing energy use and maintenance downtime. Engineers often wrestle with irregular performance, higher utility bills, and retrofit challenges when upgrading aging equipment. The design incorporates premium efficiency with NEMA Premium rating, CSA EEV compliance, and UR listings to meet stringent standards and support regulatory audits. With a 15 HP motor, 230/460 V operation, and 60 Hz synchronization, it integrates seamlessly into standard electrical infrastructure. The TEAO enclosure and compact frame deliver easy installation in tight spaces, short lead times, and predictable total cost of ownership for HVAC and process cooling systems.
Product Information
Extended Description
7BECTM2333T-G-AO ABB: Chiller/Cooling Tower 15 Hp 230 V (ECTM2333T-G-AO)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
15 AIR OVERHP,1765RPM,3PH,60HZ,254T
Ambient Temperature
40 °C
Bearing
6309, Sealed Bearing
Bearing NDE
6208
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
ECTM2333T-G-AO
Certification Agency
CSA | CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEAO
Frame Material
Iron
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
ECTM2333T-G-AO
Gross Volume
14448.906 in³
Gross Weight
268 lb
Heater Indicator
Heater Included, 115 V
Insulation Class
F
Invoice Description
15 AIR OVERHP,1765RPM,3PH,60HZ,254T,0944
Made To Order
No
Medium Description
Chiller/Cooling Tower, 15 HP, 1800 RPM, Frame Size 254T, Standard Mounting, 3 Phase, 230/460 V, 60 Hz (ECTM2333T-G-AO)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
254T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
15 Hp
Power Factor
84 %
Product Name
Chiller/Cooling Tower
Product Net Depth / Length
31 in
Product Net Height
19.625 in
Product Net Weight
268 lb
Product Net Width
23.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
36.2 A | 18.1 A
Rated Efficiency
92.40 %
Rated Speed
1765 r/min
Replaced Product ID (OLD)
7B09N187T597G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.63 in
Shaft Grounding
Shaft Grounding
Short Description
15 HP, 1800 RPM, Frame Size 254T, Standard, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The 15 HP electric motor delivers robust cooling capacity while maintaining energy efficiency, reducing operating costs for HVACR systems and process cooling. Result: lower energy bills and improved COP in data centers and manufacturing lines. Application: commercial buildings and light industrial facilities seeking dependable cooling with minimal power draw. The 254T frame and foot-mounted, horizontal mounting orientation enable straightforward retrofit into existing footprints, accelerating installation and reducing downtime during upgrades. Application: plant upgrades and retrofits where space is constrained. TEAO enclosure paired with an iron frame enhances durability and simplifies maintenance in outdoor or harsh environments, reducing service intervals and replacement costs. Application: outdoor units or factory floors with challenging ambient conditions. Direct-on-line starting offers a simple, reliable startup path with fewer components, translating to faster commissioning and lower upfront wiring complexity. Application: new builds and expansions needing rapid, economical deployment. Rated current of 36.2 A (in) / 18.1 A (out) and a rated efficiency of 92.40% support strong power management and compliance with energy standards. Application: energy reporting, utility incentives, and facility energy audits. A service factor of 1.15 provides additional margin for peak cooling loads, improving uptime in peak summer periods. Application: data centers, pharmaceutical processing, and packaging lines requiring stable, continuous cooling. Synchronous speed of 1800 r/min and 3-phase operation ensures consistent torque delivery and predictable performance. Application: continuous operation environments with tight process control. All components are designed for compatibility with 230 V / 460 V supply and 60 Hz systems, streamlining procurement and reducing engineering changes in multi-site deployments.
