ABB 7BECTM3665T-G Chiller/Cooling Tower - IE3 Premium Efficiency
Part Number: 7BECTM3665T-G
Quick Summary
ABB 7BECTM3665T-G is a 5 HP chiller/cooling tower motor designed for reliable, continuous operation in industrial cooling and HVAC water-loop systems. When uptime and energy efficiency matter, this 3-phase, dual-voltage motor delivers consistent performance with minimal maintenance. It carries strong certifications, including NEMA Premium IE3 efficiency, CSA EEV, and UR listings, signaling robust compliance for demanding environments. Designed for ease of installation and long service life, the motor integrates seamlessly with standard Baldor-Reliance components and global stock to reduce downtime and total cost of ownership. This combination of performance, certification, and availability supports critical cooling applications across manufacturing, data centers, and process industries.
Product Information
Extended Description
7BECTM3665T-G ABB: Chiller/Cooling Tower 5 Hp 230 V (ECTM3665T-G)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1750RPM,3PH,60HZ,184T,0642M,TEF
Ambient Temperature
40 °C
Bearing
6206, Sealed Bearing
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
ECTM3665T-G
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Iron
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
ECTM3665T-G
Gross Weight
115 lb
Heater Indicator
Heater Included, 115 V
Insulation Class
F
Invoice Description
5HP,1750RPM,3PH,60HZ,184T,0642M,TEFC,F1
Made To Order
No
Medium Description
Chiller/Cooling Tower, 5 HP, 1800 RPM, Frame Size 184T, Standard Mounting, 3 Phase, 230/460 V, 60 Hz (ECTM3665T-G)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
80 %
Product Name
Chiller/Cooling Tower
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
115 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
13.2 A | 6.6 A
Rated Efficiency
89.50 %
Rated Speed
1750 r/min
Replaced Product ID (OLD)
7B06J518X182G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Shaft Grounding
Shaft Grounding
Short Description
5 HP, 1800 RPM, Frame Size 184T, Standard, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: 5 HP, 3-phase motor delivers targeted power for mid-sized chillers and cooling towers, enabling reliable process cooling with modest energy use. This supports energy optimization programs and reduces operational costs in continuous duty environments. Application: Chiller loops in HVAC and industrial cooling systems needing consistent startup and load handling. Feature → IE3 Premium Efficiency → Business Impact → Application: IE3 efficiency reduces energy consumption by aligning with modern energy codes and utility incentives, lowering kWh per ton of cooling. Application: Replacement or retrofit in existing plants seeking compliance and cost savings in 60 Hz, 230/460 V environments. Feature → TEFC enclosure with Frame 184T → Business Impact → Application: Totally Enclosed Fan-Cashion (TEFC) protection protects internal windings from dust and moisture, extending motor life in challenging factory atmospheres. Application: Outdoor or semi-indoor cooling towers and equipment rooms with variable humidity.Feature → DOL Starting, 3-Phase, 60 Hz → Business Impact → Application: Direct-on-line starting simplifies drive requirements, reduces control hardware, and minimizes start-up time, improving system commissioning for chillers. Application: New installations or retrofits where simple, robust starting is preferred. Feature → 184T Frame, 1.13 in shaft, 1800 rpm synchronous speed → Business Impact → Application: Standardized mounting and shaft dimensions ease mechanical integration, spare parts sourcing, and maintenance planning. Application: Replacement motors in existing Baldor-Reliance/ABB fleets with common footprint. Feature → 1.15 Service Factor → Business Impact → Application: Higher service factor provides a cushion for peak loads and temporary overloads, reducing risk of nuisance trips. Application: Continuous duty cooling tower applications with occasional elevated loads. Feature → Dual Voltage 230 V / 460 V → Business Impact → Application: Flexibility to match plant electrical infrastructure, simplifying electrical design and stock management. Application: Plants with mixed voltage environments or future expansion plans.
