ABB EHPM3615T Hydraulic Pump - CSA EEV Certified
Part Number: 7BEHPM3615T
Quick Summary
ABB EHPM3615T hydraulic pump delivers reliable high-torque fluid transfer for heavy-duty hydraulic systems used in industrial machinery. In demanding environments, startups and downtime are costly, so consistent performance with minimal maintenance is essential. With CSA EEV and UR certifications and IE3 premium efficiency, this pump meets safety and energy standards while reducing operating costs. Designed for 230/460 V, 3-phase 60 Hz operation and 1755 r/min, it integrates with existing Baldor-Reliance drive trains, delivering faster procurement, dependable uptime, and cost-per-horsepower savings for OEMs and end users.
Product Information
Extended Description
7BEHPM3615T ABB: Hydraulic Pump 5 Hp 230 V (EHPM3615T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1755RPM,3PH,60HZ,184TYZ,3642M,T
Ambient Temperature
40 °C
Bearing
6208, Sealed Bearing
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
EHPM3615T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
36LYL541: Dimension Sheet
Drive End Flange Type
SAE Pump
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
184
Frequency (f)
60 Hz
Global Commercial Alias
EHPM3615T
Gross Volume
3496.049 in³
Gross Weight
93 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
5HP,1755RPM,3PH,60HZ,184TYZ,3642M,TEFC,F
Made To Order
No
Medium Description
Hydraulic Pump, 5 HP, 1800 RPM, Frame Size 184Tyz, SaePump Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (EHPM3615T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184TYZ
Mounting Orientation
Horizontal
Mounting Position
F3
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
78 %
Product Name
Hydraulic Pump
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
93 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
13.4 A | 6.7 A
Rated Efficiency
89.50 %
Rated Speed
1755 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.57 in
Short Description
5 HP, 1800 RPM, Frame Size 184Tyz, SaePump, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature: 5 HP hydraulic pump with TEFC enclosure and 3-phase operation. Business Impact: Provides durable protection in harsh environments and reliable startup, minimizing unplanned downtime. Application: Ideal for industrial presses, conveyors, and mobile hydraulic systems that demand steady torque at 1755 r/min. Feature: IE3 premium efficiency and dual voltage 230/460 V. Business Impact: Reduces energy consumption and complies with modern energy codes, lowering operating costs. Application: Suitable for continuous-duty loads where energy intensity matters, such as automated material handling and packaging lines. Feature: Frame Size 184TYZ, SAE pump flange, and foot mounting. Business Impact: Simplifies installation and retrofit within existing bases and drive systems, cutting installation time. Application: Retrofit projects in Baldor-Reliance compatible assemblies. Feature: Direct On Line starting and 1.15 service factor. Business Impact: Fast, simple electrical hookup with robust overload tolerance, improving line uptime. Application: OEM control panels and plant flex-lines that require immediate torque at startup. Feature: 230 V / 460 V, 60 Hz, 1755 r/min, 1.57 in shaft, 13.4 A | 6.7 A rated current. Business Impact: Clear electrical budgeting and predictable performance across global sites. Application: Standardized across multi-site facilities, reducing part diversity and inventory costs. Feature: Certifications and protection: IE3 efficiency, TEFC enclosure, NEMA compatibility, CSA EEV, UR listing. Business Impact: Improves regulatory alignment and long-term compliance, lowering risk for audits. Application: Suitable for regulated industries and energy-conscious facilities seeking reliable hydraulic pumping solutions.
