ABB 7BEJM3545 Pump Motor - IE3 Premium Efficiency
Part Number: 7BEJM3545
Quick Summary
ABB 7BEJM3545 Pump Motor is a 1 HP, 3-phase TEFC motor designed for robust pumping in industrial water handling, HVAC, and process systems. It delivers reliable torque and steady flow, even under variable loads, helping maintain consistent system performance. Operators often struggle with downtime and energy inefficiency when selecting undersized or outdated motors; this model addresses that by combining a 56J frame, C-Face mounting, and direct-on-line starting for rapid, dependable installation. With UL/CSA certifications and NEMA alignment, the motor meets critical safety and performance standards while delivering premium efficiency (IE3). In practice, facilities gain lower energy costs, simpler maintenance, and improved uptime, all supported by readily available stock and quick fulfillment.
Product Information
Extended Description
7BEJM3545 ABB: Pump Motor 1 Hp 208 V (EJM3545)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,3450RPM,3PH,60HZ,56J,3420M,TEFC
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
EJM3545
Certification Agency
C UR US ENERGY | CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
34LYK508: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
EJM3545
Gross Volume
2110.969 in³
Gross Weight
27 lb
IDEA Granular Category Code (IGCC)
1320 >> Pump motor AC
Insulation Class
B
Invoice Description
1HP,3450RPM,3PH,60HZ,56J,3420M,TEFC,F1,N
Made To Order
No
Medium Description
56J Jet Pump, 1 HP, 3600 RPM, Frame Size 56J, C-Face Mounting, 3 Phase, TEFC Enclosure, 208-230/460 V, 60 Hz (EJM3545)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
56J
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
82 %
Product Name
56J Jet Pump
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
27 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.4 A | 3.2 A | 1.6 A
Rated Efficiency
77 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.40
Shaft Diameter
0.63 in
Short Description
1 HP, 3600 RPM, Frame Size 56J, C-Face, 3 PH, TEFC, 208-230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101107
Voltage Rating
208 V | 230 V | 460 V
ABB 7BEJM3545 features a robust 56J frame and TEFC enclosure, which translates to a compact yet durable pump motor suitable for dirty or dusty industrial environments. The business impact is clear: longer service intervals and reduced maintenance overhead due to reliable ball bearings (6203) and a high-strength steel frame, enabling uninterrupted pumping in water treatment and industrial fluids handling. Application-wise, it fits horizontal mounting with C-face alignment, streamlining installation on standard bases and reducing commissioning time. The 3-phase, 2-pole design at 60 Hz delivers 3450 r/min rated speed (synchronous 3600 r/min), supporting direct-on-line starting for simple integration with existing drives or mains. The motor’s efficiency is IE3 premium, lowering energy consumption in continuous duty applications and supporting sustainability targets. Compatibility with 208-230/460 V supplies and a 1.40 service factor helps ensure stable performance across a range of pump load profiles, while stock availability and 0 day lead time minimize downtime for critical process lines. Industry insight shows that 56J TEFC motors are a common standard in mid-size pumping systems, offering a proven balance of efficiency, durability, and maintenance cost control. A ready-to-install solution with UL/CSA certification and NEMA compliance reduces compliance risk and accelerates procurement for procurement teams seeking reliable in-stock motors. In short, this motor supports cost-conscious operations pursuing energy savings, rugged design for continuous duty, and straightforward installation in pump-based processes.
Get a Quick Quote for a ABB 7BEJM3545
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BEJM3545?
Enquire Now
FAQs
Yes. The 7BEJM3545 is a 3-phase motor rated for 208-230/460 V and 60 Hz, designed for direct-on-line starting. Its 56J frame and C-face mounting simplify integration into standard pump assemblies, and the footless base supports versatile installation in compact spaces.
Key specs include 1 HP output, 3450 r/min rated speed (3600 r/min synchronous), 60 Hz, 3-phase, 56J frame, TEFC enclosure, and a service factor of 1.40. It also features IE3 premium efficiency and insulation class B, which improves energy performance and operating life in continuous duty pump applications.
This motor is ideal for small to mid-size pump installations in water treatment, HVAC pumping loops, agricultural irrigation, and process fluid transfer. Its robust frame, TEFC enclosure, and direct-on-line starting make it well-suited for environments with dust or moisture while delivering reliable pump operation.
The motor carries UL/CSA certifications (UR and CSA EEV listed), plus NEMA standards adherence, ensuring safety, electrical compatibility, and energy efficiency in industrial settings. These certifications simplify compliance for regulated facilities and support risk-managed procurement.
Lead time is listed as 0 day, with stock at multiple warehouses, reducing downtime. Warranty terms specify that warranty returns are required for warranty-related issues. Routine maintenance is straightforward due to the TEFC enclosure and standard 56J frame, which aligns with readily available spare parts.
