ABB 7BEJM3550-5 Pump Motor - IE3 Premium
Part Number: 7BEJM3550-5
Quick Summary
ABB 7BEJM3550-5 Pump Motor delivers 1.5 HP for reliable pumping in water transfer and processing lines. Engineers often contend with downtime from mismatched voltage, excessive energy use, and complex installation in tight spaces. This motor meets CSA EEV, NEMA Premium IE3, and UR safety certifications, reinforcing compliance across North American and international facilities. With a TEFC enclosure, 575 V three-phase operation, and a C-face drive end flange, it is designed for rugged, heavy-duty service. The motor’s stock availability across multiple warehouses and a zero-day lead time helps shorten procurement cycles, while the 56J frame and 0.63 in shaft diameter support straightforward integration into existing systems. This combination delivers operational efficiency and reliable lifecycle value for industrial users.
Product Information
Extended Description
7BEJM3550-5 ABB: Pump Motor 1.50 Hp 575 V (EJM3550-5)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5HP,3450RPM,3PH,60HZ,56J,3520M,TE
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
EJM3550-5
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
C-Face
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
EJM3550-5
Gross Weight
38 lb
Insulation Class
F
Invoice Description
1.5HP,3450RPM,3PH,60HZ,56J,3520M,TEFC,F1
Made To Order
No
Medium Description
56J Jet Pump, 1.5 HP, 3600 RPM, Frame Size 56J, C-Face Mounting, 3 Phase, 575 V, 60 Hz (EJM3550-5)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
56J
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1.50 Hp
Power Factor
85 %
Product Name
56J Jet Pump
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
38 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.5 A
Rated Efficiency
84 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.30
Shaft Diameter
0.63 in
Short Description
1.5 HP, 3600 RPM, Frame Size 56J, C-Face, 3 PH, 575 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
575 V
Feature: 1.5 HP, 575 V three-phase operation with 60 Hz supply and a 56J frame. Business Impact: Delivers reliable motor starting torque and steady flow with low energy waste, reducing unplanned downtime. Application: Ideal for jet pump setups in water transfer and processing lines where consistent performance matters. Feature: IE3 Premium Efficiency with Insulation Class F. Business Impact: Lower operating temperatures and energy costs over the motor lifecycle, supporting sustainability goals and reduced cooling requirements. Application: Municipal and industrial water systems seeking compliance with premium efficiency standards. Feature: TEFC enclosure, C-Face drive end flange, horizontal mounting. Business Impact: Enhanced durability in harsh environments and straightforward alignment during retrofit or new installation with minimal downtime. Application: Industrial pump stations and retrofit projects where footprint and compatibility matter. Feature: Direct on Line starting and stock-availability across multiple warehouses. Business Impact: Quick commissioning, reduced spare-part inventory, and fast replacement in 0-day lead-time environments. Application: Plants aiming to minimize downtime and optimize procurement cycles for critical pumping applications. Feature: 56J frame, shaft diameter 0.63 in, bearing arrangement (6205 Ball). Business Impact: Standardized mounting and predictable wear characteristics simplify maintenance and part sourcing. Application: Jet pump and water-handling systems where interchangeability with existing spares is crucial.
Get a Quick Quote for a ABB 7BEJM3550-5
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BEJM3550-5?
Enquire Now
FAQs
Yes. This pump motor is designed for 575 V, 60 Hz, three-phase service and features a TEFC enclosure with a C-Face drive end flange for straightforward installation and reliable protection in demanding environments.
The motor delivers 1.5 HP, rated current 1.5 A, rated speed 3450 r/min with a 3600 r/min synchronous speed, efficiency around 84%, and power factor near 85%. It carries IE3 Premium efficiency and insulation class F, suitable for energy-conscious industrial applications.
Yes. It is specifically marketed as a 56J Jet Pump, with a 56J frame, 575 V, 3-phase operation, and horizontal mounting, making it a strong fit for water transfer and processing line pumping.
The motor is certified for CSA EEV, NEMA Premium, and UR recognition, providing compliance support for safety and efficiency requirements in North American and international facilities.
The model is stocked across multiple warehouses with a 0 day lead time, enabling rapid procurement. Warranty terms require that warranty returns follow the supplier’s warranty policy; in general, defective units should be returned per the stated policy.
