ABB 7BEJMM3155T Pump Motor - IE3 Premium Efficiency
Part Number: 7BEJMM3155T
Quick Summary
The ABB 7BEJMM3155T pump motor drives close-coupled pumps for commercial and industrial fluid handling. A common challenge for engineers is selecting a motor that matches a US 60 Hz supply while delivering reliable protection and simple installation. This model carries CSA, CSA EEV and UR certifications and uses a NEMA Design B frame with premium IE3 efficiency, ensuring compliance and energy savings. Designed for 3-phase operation at 230/460 V, 60 Hz with a 145JM frame, foot-mounted C-face mounting supports quick retrofits and minimal downtime. Stocked at multiple warehouses and backed by immediate lead times, it helps maximize uptime and predictable procurement.
Product Information
Extended Description
7BEJMM3155T ABB: Pump Motor 2 Hp 230 V (EJMM3155T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,3450RPM,3PH,60HZ,3524M,N
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6206 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
EJMM3155T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
B
Dimension Diagram
35LYT922: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
OPSB
Frame Material
Steel
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
EJMM3155T
Gross Volume
3496.049 in³
Gross Weight
44 lb
Horsepower Rating UL/CSA
2.000 Hp
IC Class
OPSB
IDEA Granular Category Code (IGCC)
1320 >> Pump motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
2HP,3450RPM,3PH,60HZ,3524M,N
Lubrication
Regreasable
Made To Order
No
Medium Description
Close Coupled Pump, 2 HP, 3600 RPM, Frame Size 145Jm, C-Face Mounting, 3 Phase, OPSB Enclosure, 230/460 V, 60 Hz (EJMM3155T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
145JM
Motor Frame Suffix
JM
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
87 %
Product Name
Close Coupled Pump
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
44 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5 A | 2.5 A
Rated Efficiency
85.50 %
Rated Speed
3450 r/min
Replaced Product ID (OLD)
7B35T922Q054G1
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.88 in
Short Description
2 HP, 3600 RPM, Frame Size 145Jm, C-Face, 3 PH, OPSB, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101107
Voltage Code
K
Voltage Rating
230 V | 460 V
Feature → Premium IE3 efficiency (2 HP 3-phase) reduces energy consumption and operating costs in pump systems. Business Impact → Lower energy bills and improved sustainability across continuous-duty applications. Application → Perfect for close-coupled pumps in water transfer or cooling circuits where steady 60 Hz power and energy efficiency matter. Feature → OPSB enclosure and rugged construction withstands industrial environments. Business Impact → Enhanced protection against dust and moisture, longer motor life, and reduced maintenance. Application → Suitable for factories and processing plants with ambient conditions up to 40 °C and moderate altitude, ensuring reliable operation. Feature → Frame Size 145JM with foot-mounted, C-face mounting. Business Impact → Easy installation, simplified retrofits, and compatibility with existing mounting footprints. Application → Ideal for upgrading legacy pump motors in retrofit projects with minimal downtime and predictable fitment. Feature → Direct On Line starting and 3-phase 230/460 V capability. Business Impact → Simplified commissioning, fewer start components, and lower startup torque reaction. Application → Supports straightforward startup in pump systems where fast engagement is required. Feature → CSA/CSA EEV/UR certifications and NEMA Design Code B. Business Impact → Compliance with stringent safety standards and reliable performance data. Application → Suitable for regulated industries and OEMs needing verifiable safety documentation. Feature → Stocked-at-warehouses with 0 day lead time and clear warranty terms. Business Impact → Minimized downtime and rapid procurement for maintenance and uptime guarantees. Application → Appropriate for mission-critical pumping in manufacturing and processing facilities with tight maintenance windows.
