ABB 7BEM3550T General Purpose Motor - IE3 Premium
Part Number: 7BEM3550T
Quick Summary
General purpose motor 7BEM3550T delivers reliable 1.5 HP, 230 V three-phase power for standard industrial drives like conveyors and pumps. Engineers often face downtime and inconsistent performance when sourcing off-spec motors; this unit offers rapid availability and robust design. It aligns with NEMA standards and delivers IE3 efficiency, CSA/UR certifications, and a TEFC enclosure for harsh environments. Stocked at multiple warehouses with 0-day lead time, it supports procurement agility, while the 143T frame and 60 Hz operation ensure plug-and-play installation and broad compatibility for capital projects and spares programs.
Product Information
Extended Description
7BEM3550T ABB: General Purpose Motor 1.5 Hp 230 V (EM3550T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5HP,3500RPM,3PH,60HZ,3520M,143T,N
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
EM3550T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
B
Dimension Diagram
35LYT638: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
Standard
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
143
Frequency (f)
60 Hz
Global Commercial Alias
EM3550T
Gross Volume
2110.969 in³
Gross Weight
36 lb
Horsepower Rating UL/CSA
1.500 Hp
IC Class
TEFC
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
NEMA Foot
Insulation Class
F
Invoice Description
1.5HP,3500RPM,3PH,60HZ,3520M,143T,N
Lubrication
Regreasable
Made To Order
No
Medium Description
General Purpose 3PH Enclosed, 1.5 HP, 3600 RPM, Frame Size 143T, Standard Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (EM355
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
143T
Motor Frame Suffix
T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1.5 Hp
Power Factor
85 %
Product Name
General Purpose 3PH Enclosed
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
36 lb
Product Net Width
11.5 in
Product Type
NEMA_PREMIUM
Quote Only
No
Rated Current (In)
3.8 A | 1.9 A
Rated Efficiency
84 %
Rated Speed
3500 r/min
Replaced Product ID (OLD)
7B35T638M760G1
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.88 in
Short Description
1.5 HP, 3600 RPM, Frame Size 143T, Standard, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
Menden, Germany | China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101112
Voltage Code
L
Voltage Rating
230 V | 460 V
Feature TEFC enclosure and 143T frame size provides robust protection against dust and moisture while maintaining compatibility with standard mounting feet. Business Impact Reduced maintenance and longer service life in demanding environments, lowering total cost of ownership. Application Suitable for general purpose drives in conveyors, pumps, and fans, with straightforward bolt-on installation and reliable performance in typical factory settings. Feature Dual voltage 230/460 V and 60 Hz operation enables flexible deployment across facilities with varying power infrastructure. Business Impact Simplified inventory management and fewer adapters, accelerating project readiness and reducing electrical retrofit risk. Application Ideal for 3-phase industrial systems needing consistent torque and dependable startup with direct-on-line (DOL) control. Feature IE3 efficiency and 1.15 service factor deliver energy savings and improved uptime in continuous-duty applications. Business Impact Lower energy costs and improved motor longevity under continuous operation. Application Best suited for continuous-duty tasks in material handling and process equipment. Feature Regreasable lubrication and standard bearings (6205 ball) support long intervals between maintenance, accelerating throughput. Business Impact Fewer service interruptions and extended interval between inspections, improving overall line productivity. Application Suitable for machine tools and packaging lines that require predictable performance and low maintenance overhead. Feature 0-day lead time and stocked warehouses across regions ensure rapid procurement, reducing downtime risk. Business Impact Faster project ramp-up and shorter time-to-value for capital projects. Application Ideal for spare parts programs and maintenance planning in manufacturing facilities with global footprint.
