ABB 7BEM3558T-57 General Purpose Motor - IE3 Efficiency
Part Number: 7BEM3558T-57
Quick Summary
ABB 7BEM3558T-57 General Purpose Motor is a robust 2 HP 3-phase unit designed for pumps, fans, and conveyors in industrial plants. It delivers reliable, ready-to-run performance to minimize downtime and optimize equipment uptime. This motor targets common pain points such as long supplier lead times and variable efficiency, with immediate stock at multiple warehouses and a 0-day lead time. It carries CE, CSA, IE3, UR, and WEEE certifications, ensuring global compliance and safer operation. Built with a TEFC enclosure and a 145T frame, it supports straightforward installation and dependable service life, while 230/400 V operation and a 1.15 service factor boost compatibility with existing drives and power systems. Ideal for cost-conscious facilities seeking efficient, durable 3-phase motors.
Product Information
Extended Description
7BEM3558T-57 ABB: General Purpose Motor 2 Hp 230 V (EM3558T-57)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2/1.5KWHP,1460RPM,3PH,50HZ,145T,352
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
EM3558T-57
Certification Agency
CE | CSA | IE3 | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYAA001: Dimension Sheet
Drive End Flange Type
Standard
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
145
Frequency (f)
50 Hz
Global Commercial Alias
EM3558T-57
Gross Volume
3496.049 in³
Gross Weight
45 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
2/1.5KWHP,1460RPM,3PH,50HZ,145T,3528M,TE
Made To Order
No
Medium Description
General Purpose 3PH Enclosed, 2/1.5 HP, 1500 RPM, Frame Size 145T, Standard Mounting, 3 Phase, TEFC Enclosure, 230/400 V, 50 Hz (EM3
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
145T
Motor Frame Suffix
T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
73 %
Product Name
General Purpose 3PH Enclosed
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
45 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.9 A | 3.4 A
Rated Efficiency
85.30 %
Rated Speed
1445 r/min
Replaced Product ID (OLD)
7B35AA001G303G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Short Description
2/1.5 HP, 1500 RPM, Frame Size 145T, Standard, 3 PH, TEFC, 230/400 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 400 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
The 2 HP, 3-phase design at 230/400 V with IE3 efficiency delivers measurable energy savings and reduced operating costs, improving overall plant energy intensity. This feature translates to lower utility bills and longer motor life when integrated with variable speed drives and soft-start systems in conveyors and fans. The TEFC enclosure provides reliable protection against dust, moisture, and harsh environments, enabling straightforward installation in open plant spaces or retrofit projects without costly enclosures. With a 145T frame and foot-mounted base, installation is quick and compatible with standard mounting rails, reducing commissioning time and hardware procurement risk. The NEMA B design, 4-pole construction, and 1445 r/min speed support compact footprint integration with existing belts and gear systems, while direct-on-line starting keeps control simple and cost-effective. Bearings (6205 ball) and insulation class F assure durability for continuous duty in 40 °C ambient conditions, translating into fewer maintenance cycles and lower life-cycle costs. Stocked at multiple warehouses with a 0-day lead time and a clear warranty policy, this motor minimizes downtime and procurement complexity for global engineering teams. Industry-specific context shows that frame 145T and 0.88 in shaft diameter align with common pump and fan assemblies, making replacements fast and predictable. Overall, the motor meets stringent compliance (CE, CSA, IE3, UR, WEEE) while delivering high reliability for continuous operation in demanding industrial environments.
Get a Quick Quote for a ABB 7BEM3558T-57
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BEM3558T-57?
Enquire Now
FAQs
This is a foot-mounted, 3-phase motor designed for 230/400 V operation with a 145T frame. It uses a TEFC enclosure and is suitable for direct-on-line startup, simplifying installation in horizontal mounting configurations and standard industrial power systems.
The unit provides 2 HP of output at 1445 r/min, with 4 poles and 50 Hz operation. It features IE3 efficiency, a 1.15 service factor, and a shaft diameter of 0.88 inches to fit typical coupling assemblies and mounting hardware.
Yes. It carries CE, CSA, IE3, UR, and WEEE certifications and is produced under Baldor-Reliance branding in the United States, ensuring compliance and robust support for multinational installations.
Lead time is 0 day, with stock at multiple warehouses including locations in the US, GB, SG, and CN. This enables rapid fulfillment and reduces project delays for regional and global deployments.
The motor is designed for continuous duty with a TEFC enclosure and standard bearings for long life. Warranty terms indicate that warranty returns are required if a fault occurs, so keep the original packaging and documentation for smooth service.
