ABB 7BEMM2334 Motors & Drives - TEFC, 15kW 60Hz
Part Number: 7BEMM2334
Quick Summary
ABB 7BEMM2334 Motors & Drives deliver reliable, high-efficiency performance for conveyors, pumps, and fans in demanding industrial environments. This 15 kW, 1770 RPM, 3-phase motor with a TEFC enclosure is designed to keep equipment running with minimal maintenance and downtime. Faced with fluctuating loads, harsh ambient conditions, or tight procurement schedules, you need a motor that installs quickly and operates predictably. The spec confirms IEC standards compliance and insulation class F, and notes a continuous duty rating and a regreasable lubrication scheme for long life; however, explicit CE or IP certifications are not listed in the provided data. By choosing a standard mounting, multi-warehouse stock, and a readily available warranty path, you can reduce total cost of ownership and streamline your maintenance planning.
Product Information
Extended Description
7BEMM2334 ABB: 15KW,1770RPM,3PH,60HZ,D160L,0960M,TEFC,F
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
15KW,1770RPM,3PH,60HZ,D160L,0960M,T
Invoice Description
15KW,1770RPM,3PH,60HZ,D160L,0960M,TEFC,F
Product Name
LV Baldor IEC Motors
Product Type
Undefined
Made To Order
No
Minimum Order Quantity
1 piece
Order Multiple
1 piece
Selling Unit of Measure
piece
Country of Origin
United States (US)
Customs Tariff Number
85015230
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Medium Description
Standard Mounting, 3 Phase, TEFC Enclosure, (EMM2334)
Short Description
Standard, 3 PH, TEFC,
Electrical Data
Temperature Class Default
--
Frequency (f)
60 Hz
Output Power
15 Hp
Altitude
1000 m
Ambient Temperature
40 °C
IC Class
TEFC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
Insulation Class
F
Direction of Rotation
Both sides
Number of Poles (High)
4
Two Speed Motor
No
Type of Duty
Continuous
Voltage Code
H
Frame Material
Iron
Frame Size
160
Bearing
6309, Ball
Bearing NDE
6208
Lubrication
Regreasable
IM Class
F2
Product Net Depth / Length
27 in
Product Net Height
17.438 in
Product Net Width
20.5 in
Product Net Weight
141.974 kg
Gross Weight
141.974 kg
Standards
IEC
UNSPSC
26101115
Feature: TEFC enclosure and 4-pole design provide robust protection against dust, moisture, and heat, ensuring stable performance in harsh environments. Business Impact: minimizes unplanned downtime and extends bearing life, lowering maintenance costs. Application: ideal for conveyors, pumps, and fans in food processing, automotive, and packaging lines. Long-tail keywords weaved in include TEFC motor, 4-pole motor, and IEC motor, aligning with industry search terms. Feature: 15 kW, 1770 RPM at 60 Hz delivers strong starting torque and consistent speed control for heavy loads. Business Impact: improves throughput and reduces cycle times in continuous processes. Application: suitable for line drives and process equipment requiring reliable speed under variable loads. Feature: Insulation Class F with ambient 40 °C and altitude 1000 m supports operation in moderate industrial climates. Business Impact: reduces overheating risk and maintains efficiency across plant elevations. Application: critical for facilities near variable climate zones or growth sites. Feature: Regreasable bearings (6309, Ball) and IM Class F2 enable long service intervals and effective lubrication management. Business Impact: lowers lubrication downtime and maintenance costs, extending service life. Application: ensures predictable performance in long-running conveyors and fans. Feature: Stocked at multiple warehouses with 0-day lead time, aiding rapid deployment and spare-parts planning. Business Impact: minimizes downtime during upgrades or expansions and improves total cost of ownership. Application: supports just-in-time maintenance programs and procurement efficiency. Feature: Warranty terms indicate returns for warranty issues, reducing risk for purchase decisions. Business Impact: provides risk mitigation and confidence for capital investments. Application: aligns with enterprise asset management and reliability-centered maintenance strategies.
