ABB 7BEPCL1317M Pressure Washer - CSA UR
Part Number: 7BEPCL1317M
Quick Summary
ABB 7BEPCL1317M Pressure Washer cleans industrial surfaces with dependable 2 HP power for heavy-duty cleaning. It meets the needs of production floors, equipment bays, and tooling decks where consistent high-pressure output matters. The design addresses downtime from stubborn buildup by delivering reliable performance from a 115 V, single-phase supply. With CSA and UR safety certifications and compatibility with NEMA configurations, operators gain confidence in safe, compliant operation around personnel and machinery. The unit’s 56C frame and open enclosure simplify installation and maintenance, while multi-warehouse stock supports fast procurement and reduced lead times for your maintenance schedules.
Product Information
Extended Description
7BEPCL1317M ABB: Pressure Washer 2 Hp 115 V (EPCL1317M)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,3470RPM,1PH,60HZ,56C,3540LC,OPE
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
EPCL1317M
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
C-Face
Efficiency Level
2015 Small Motor Standard | Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
EPCL1317M
Gross Volume
3496.049 in³
Gross Weight
66 lb
Insulation Class
B
Invoice Description
2HP,3470RPM,1PH,60HZ,56C,3540LC,OPEN,F1
Made To Order
No
Medium Description
Pressure Washer, 2 HP, 3600 RPM, Frame Size 56C, C-Face Mounting, 1 Phase, OPEN Enclosure, 115/230 V, 60 Hz (EPCL1317M)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
L
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
99 %
Product Name
Pressure Washer
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
66 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
15.6 A | 7.8 A
Rated Efficiency
82.90 %
Rated Speed
3470 r/min
Replaced Product ID (OLD)
7B35T967L138
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
2 HP, 3600 RPM, Frame Size 56C, C-Face, 1 PH, OPEN, 115/230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
115 V | 230 V
Feature → Business Impact → Application: The 2 HP motor delivers strong cleaning power at 3470 r/min, enabling faster cycle times and reduced labor costs in industrial washing applications; ideal for floor and equipment cleaning in manufacturing environments. The 115 V | 230 V, 60 Hz single-phase setup minimizes electrical footprint and simplifies electrical wiring, lowering installation complexity and project risk for upgrade or retrofit projects. Open enclosure with a C-face mounting and 56C frame supports flexible installation in tight spaces, streamlining retrofits and hallway placements in service shops and assembly lines. A 1-phase configuration reduces hardware requirements and maintenance overhead, improving reliability and uptime in continuous-duty cleaning cycles. The 6205 ball bearings and B insulation class contribute to longer motor life and reduced maintenance intervals, translating to lower total cost of ownership. CSA | UR certifications reinforce compliance and safety, while stock availability across U.S. and international warehouses shortens procurement lead times. These features collectively deliver measurable gains in energy efficiency, safety compliance, and operational uptime for industrial cleaning operations.
