ABB 7BERL1309A Fan & Blower - Open Enclosure 1PH 60Hz
Part Number: 7BERL1309A
Quick Summary
The ABB 7BERL1309A Fan & Blower delivers dependable air movement for compact electrical enclosures and light-duty industrial cooling. In many installations, designers struggle with space limits, dual-voltage availability, and mounting constraints that complicate retrofits. This model addresses those pain points with a 1 HP, 3480 RPM, single-phase design that runs on 115/230 V and uses a resilient Mount. It carries NEMA design alignment and CUR US ENERGY certification, reinforcing compliance in regulated environments. Open enclosure access simplifies maintenance and service intervals, while the 56H frame size and 11.5 in width fit compact blower housing footprints. For manufacturers, this combination reduces installation time and supports reliable continuous operation in demanding production environments.
Product Information
Extended Description
7BERL1309A ABB: Fan and Blower 1 Hp 115 V (ERL1309A)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,3480RPM,1PH,60HZ,56H,3524LC,OPE
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ERL1309A
Certification Agency
C UR US ENERGY
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYE4041: Dimension Sheet
Drive End Flange Type
Resilient Mount
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
ERL1309A
Gross Volume
2110.969 inÂł
Gross Weight
36 lb
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
Insulation Class
F
Invoice Description
1HP,3480RPM,1PH,60HZ,56H,3524LC,OPEN,F1
Made To Order
No
Medium Description
Fan and Blower, 1 HP, 3600 RPM, Frame Size 56H, ResilientMount Mounting, 1 Phase, OPEN Enclosure, 115/230 V, 60 Hz (ERL1309A)
Minimum Order Quantity
1 piece
Motor Base Type
Resilient
Motor Frame Size
56H
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
99 %
Product Name
Fan and Blower
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
36 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
7.8 A | 3.9 A
Rated Efficiency
82 %
Rated Speed
3480 r/min
Replaced Product ID (OLD)
7B35E4041L157G1
Selling Unit of Measure
piece
Service Factor
1.25
Shaft Diameter
0.63 in
Short Description
1 HP, 3600 RPM, Frame Size 56H, ResilientMount, 1 PH, OPEN, 115/230 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
115 V | 230 V
Open enclosure design simplifies field service and routine cleaning, translating to less downtime and faster maintenance. The direct access improves filter replacement, wiring checks, and visual inspections, boosting overall equipment availability in manufacturing lines and packaging operations. High starting torque from a 1 HP, 3480 RPM motor delivers effective heat removal in tight spaces, reducing hotspot risk in gear boxes and control cabinets. Flexible voltage support (115V/230V) minimizes the need for redundant transformers or power conversion, enabling quicker installations and lower commissioning costs in plants with mixed electrical infrastructure. The resilient 56H frame and open mounting system reduce vibration transmission and simplify alignment during retrofit projects, cutting installation time and improving long-term reliability. Direct On Line starting and a single-speed design simplify panel integration and prevent control-system complexity, while a service factor of 1.25 provides margin for transient loads common in cooling applications. Overall, the unit pairs a compact footprint with robust performance metrics, addressing common buyer concerns around footprint, energy use, and lifecycle costs in HVAC and industrial cooling applications.
