ABB 7BERL1313A Fan and Blower - 1.5HP, 115V, C UR US ENERGY
Part Number: 7BERL1313A
Quick Summary
The ABB 7BERL1313A Fan and Blower moves air for cabinet cooling and compact machinery ventilation. In space constrained panels, engineers need a compact, single phase solution that minimizes wiring, installation effort, and downtime. This model carries UL/UR energy certification, follows NEMA design standards, and supports 60 Hz operation on a 115/230 V supply. Designed for OEMs and service teams, it delivers dependable cooling in harsh environments while keeping the footprint small. The resilient mount and open enclosure simplify installation and maintenance, helping to accelerate service cycles and reduce field labor costs. By combining robust construction with accessible spare parts worldwide, this blower supports scalable, reliable industrial air handling for a broad range of applications.
Product Information
Extended Description
7BERL1313A ABB: Fan and Blower 1.5 Hp 115 V (ERL1313A)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5HP,3480RPM,1PH,60HZ,56H,3532LC,O
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ERL1313A
Certification Agency
C UR US ENERGY
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYF554: Dimension Sheet
Drive End Flange Type
Resilient Mount
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
ERL1313A
Gross Volume
3496.049 in³
Gross Weight
52 lb
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
Insulation Class
B
Invoice Description
1.5HP,3480RPM,1PH,60HZ,56H,3532LC,OPEN,F
Made To Order
No
Medium Description
Fan and Blower, 1.5 HP, 3600 RPM, Frame Size 56H, ResilientMount Mounting, 1 Phase, OPEN Enclosure, 115/230 V, 60 Hz (ERL1313A)
Minimum Order Quantity
1 piece
Motor Base Type
Resilient
Motor Frame Size
56H
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
L
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1.5 Hp
Power Factor
99 %
Product Name
Fan and Blower
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
52 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
11.8 A | 5.9 A
Rated Efficiency
82 %
Rated Speed
3480 r/min
Replaced Product ID (OLD)
7B35F554L162G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
1.5 HP, 3600 RPM, Frame Size 56H, ResilientMount, 1 PH, OPEN, 115/230 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
115 V | 230 V
Feature: 115 V / 230 V single-phase operation. Business Impact: Simplified wiring and compatibility with standard control panels lowers installation time and reduces miswiring risk. Application: OEM cabinet cooling and open panel installations. Feature: 1.5 HP motor delivering 3480 r/min with 2-pole design. Business Impact: Consistent high airflow with responsive cooling in tight enclosures, improving thermal margins and product reliability. Application: Enclosures, small machinery cooling, process ventilation. Feature: Frame Size 56H and open enclosure with resilient mounting. Business Impact: Standardized footprint enables quick retrofits and straightforward mounting with vibration damping to minimize noise and wear. Application: Retrofit projects and new equipment in space constrained environments. Feature: Efficiency and power characteristics (PF 99 %, rated efficiency 82 %). Business Impact: Lower energy consumption and reduced running costs over life cycle, aiding compliance with energy programs. Application: Continuous operation in manufacturing lines. Feature: Bearing and construction (6203 ball bearing, steel frame). Business Impact: Enhanced durability and lower maintenance intervals in demanding environments. Application: Long-term OEM deployments in temperature up to 40 °C. Feature: Stocked at multiple warehouses and 0 day lead time as per supplier data. Business Impact: Shorter procurement cycles and faster production line start-ups, reducing downtime risk. Application: Global procurement for large-scale rollout with reliable supply.
