ABB 7BERM3010 Fan and Blower - 0.5 HP, 60 Hz
Part Number: 7BERM3010
Quick Summary
ABB 7BERM3010 Fan and Blower delivers compact air movement for cooling and ventilation in industrial equipment and control panels. This open-enclosure, 3-phase unit helps prevent heat buildup that can degrade performance and shorten component life, addressing downtime and unplanned maintenance. With a 0.5 horsepower motor, 1725 RPM and 60 Hz rating, it provides reliable airflow under continuous duty. The design aligns with NEMA standards and UR-US energy certification, supporting procurement and compliance across regions. Global sourcing is simplified by a 230/460 V, single-speed solution that reduces stocking complexity. For machine builders and panel builders, the ABB ERM3010 combines performance, durability, and serviceability to protect critical cooling paths.
Product Information
Extended Description
7BERM3010 ABB: Fan and Blower 0.5 Hp 230 V (ERM3010)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.5HP,1725RPM,3PH,60HZ,48,3424M,OPEN
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ERM3010
Certification Agency
C UR US ENERGY
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
34LYK015: Dimension Sheet
Drive End Flange Type
Resilient Mount
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
48
Frequency (f)
60 Hz
Global Commercial Alias
ERM3010
Gross Volume
2110.969 in³
Gross Weight
31 lb
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
Insulation Class
B
Invoice Description
.5HP,1725RPM,3PH,60HZ,48,3424M,OPEN,F1,N
Made To Order
No
Medium Description
Fan and Blower, 0.5 HP, 1800 RPM, Frame Size 48, ResilientMount Mounting, 3 Phase, OPEN Enclosure, 230/460 V, 60 Hz (ERM3010)
Minimum Order Quantity
1 piece
Motor Base Type
Resilient
Motor Frame Size
48
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.5 Hp
Power Factor
78 %
Product Name
Fan and Blower
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
31 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.6 A | 0.8 A
Rated Efficiency
78.20 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.25
Shaft Diameter
0.5 in
Short Description
0.5 HP, 1800 RPM, Frame Size 48, ResilientMount, 3 PH, OPEN, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
230 V | 460 V
Feature → 0.5 HP, 1725 RPM, 60 Hz 3‑phase motor delivers consistent airflow with a compact footprint. Business Impact → Improves enclosure cooling efficiency and supports reliable operation in tight panel spaces, reducing thermal stress on electronics. Application → Ideal for control panels, cooling ductwork, and motor-driven equipment in manufacturing lines. Feature → Open enclosure with frame size 48 and resilient mounting provides robust support. Business Impact → Eases installation, reduces vibration transmission, and simplifies service access, lowering maintenance time. Application → Suitable for horizontal mounting on equipment racks and machine enclosures. Feature → 230/460 V voltage rating and direct-on-line start simplifies electrical integration. Business Impact → Reduces wiring complexity, part count, and start-up time, enabling faster commissioning. Application → Global projects and multi-site installations benefit from a single, versatile unit. Feature → Durable steel frame and insulation class B enable long life in demanding environments. Business Impact → Lower replacement frequency and total cost of ownership, with predictable performance. Application → Harsh factory floors, signal cabinets, and outdoor-rated enclosures. Feature → Bearing life and service factor (1.25) support reliable operation under peak loads. Business Impact → Higher uptime, reduced unplanned downtime, and improved process throughput. Application → Heavy-duty industrial cooling tasks and continuous operation scenarios. Feature → Stock availability and 0-day lead time enable accelerated project timelines. Business Impact → Shortens procurement cycles, keeps lean manufacturing on schedule, and improves time-to-market. Application → Panel upgrades, retrofits, and new line builds benefit from quick delivery. Note: Throughout, long-tail keywords such as 0.5 HP industrial fan, frame size 48 blower, 230/460 V blower, 3‑phase cooling fan, and resilient mount motor are incorporated to support relevant searches while preserving technical clarity.
