ABB 7BERM3116 Fan and Blower - 1HP Open Enclosure, 60 Hz IE2
Part Number: 7BERM3116
Quick Summary
ABB 7BERM3116 fan and blower delivers compact airflow for OEM equipment and industrial cooling applications. This 1 HP, three‑phase unit is designed for reliable operation in demanding environments with a rugged 56H frame and open enclosure. Engineers often struggle with mounting rigidity, heat buildup, and matching voltage with compact footprints; the 7BERM3116 addresses these pain points through resilient mounting, direct-on-line starting, and a broad 230/460 V, 60 Hz power range. The equipment aligns with IE2 energy efficiency targets, C-UR-US ENERGY certification, and standard NEMA design considerations, simplifying procurement and compliance. For system integrators and manufacturers, this translates to reduced installation time, predictable maintenance, and lower total cost of ownership while maintaining cooling performance.
Product Information
Extended Description
7BERM3116 ABB: Fan and Blower 1 Hp 230 V (ERM3116)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,1770RPM,3PH,60HZ,56H,3520M,OPEN
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ERM3116
Certification Agency
C UR US ENERGY
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
35LYE411: Dimension Sheet
Drive End Flange Type
Resilient Mount
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | Energy Efficiency (NEMA 12-11) | IE2
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
ERM3116
Gross Volume
2110.969 in³
Gross Weight
36 lb
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
Insulation Class
F
Invoice Description
1HP,1770RPM,3PH,60HZ,56H,3520M,OPEN,F1,N
Made To Order
No
Medium Description
Fan and Blower, 1 HP, 1800 RPM, Frame Size 56H, ResilientMount Mounting, 3 Phase, OPEN Enclosure, 230/460 V, 60 Hz (ERM3116)
Minimum Order Quantity
1 piece
Motor Base Type
Resilient
Motor Frame Size
56H
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
69 %
Product Name
Fan and Blower
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
36 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.2 A | 1.6 A
Rated Efficiency
85.50 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
1 HP, 1800 RPM, Frame Size 56H, ResilientMount, 3 PH, OPEN, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
230 V | 460 V
Feature: 56H frame steel construction with resilient mounting. Business Impact: Reduces vibration transfer and simplifies alignment, lowering mounting hardware costs and downtime. Application: Ideal for compact blowers in HVAC, electronics cooling, and process ventilation where space is limited. Feature: IE2 efficiency with 1HP output and 1770 rpm (synchronous 1800 rpm). Business Impact: Delivers measurable energy savings and cooler operating temperatures, supporting energy performance targets. Application: Continuous-duty duty in manufacturing lines and automated equipment cooling where operating cost matters. Feature: 230/460 V, 60 Hz, three-phase power with open enclosure. Business Impact: Flexible installation across regional power grids and easy wiring schemes, reducing custom cabling needs. Application: Global OEM deployments and field retrofits in control panels and machinery. Feature: Direct On Line starting and resilient mounting with F1 mounting position. Business Impact: Fast commissioning, reduced startup time, and robust vibration control in noisy plant environments. Application: OEM equipment and line-side cooling fans in packaging and material handling. Feature: NEMA design code B, insulation class F, service factor 1.15. Business Impact: Enhanced reliability in warm environments and predictable performance under transient loads. Application: Industrial plants and process lines requiring durable motors with extended service life. Feature: Frame size 56H and shaft diameter 0.63 in. Business Impact: Compatibility with common driven equipment and standardized mounting accessories, lowering spare parts complexity. Application: Retrofit projects or new builds using standard 56H components and belts/pulleys.
