ABB EWDM3550T Washdown Motor - Premium Efficiency
Part Number: 7BEWDM3550T
Quick Summary
ABB EWDM3550T is a washdown motor delivering 1.5 HP at 230 V for hygienic processing lines. This design addresses moisture, washdown cycles, and downtime that challenge productivity in food, beverage, and pharma environments. With CSA, CSA EEV, and UR certifications alongside a NEMA-compliant, TENV enclosure, it meets stringent regulatory and reliability needs. The combination of premium efficiency and a robust frame supports long-term energy cost reductions while maintaining high performance in harsh washdown conditions. For engineers and procurement teams, this motor balances reliability, efficiency, and installable compatibility with standard 143T footprints and 3-phase power systems.
Product Information
Extended Description
7BEWDM3550T ABB: Washdown Motor 1.5 Hp 230 V (EWDM3550T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5HP,3500RPM,3PH,60HZ,143T,TENV,F1
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
EWDM3550T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYS584: Dimension Sheet
Drive End Flange Type
Standard
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
143
Frequency (f)
60 Hz
Global Commercial Alias
EWDM3550T
Gross Volume
2110.969 in³
Gross Weight
48 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
1.5HP,3500RPM,3PH,60HZ,143T,TENV,F1
Made To Order
No
Medium Description
White Washdown, 1.5 HP, 3600 RPM, Frame Size 143T, Standard Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (EWDM3550T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
143T
Motor Frame Suffix
T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1.5 Hp
Power Factor
87 %
Product Name
White Washdown
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
48 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4 A | 2 A
Rated Efficiency
85.50 %
Rated Speed
3500 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Short Description
1.5 HP, 3600 RPM, Frame Size 143T, Standard, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: Premium Efficiency motor class reduces energy consumption and operating costs on continuous-duty conveyors and processing lines, improving total cost of ownership while meeting sustainability goals. The 1.5 HP output with a 3500 r/min nominal speed (3600 r/min synchronous) enables strong startup torque and consistent performance in belt-driven systems. 143T frame size and foot-mounted base simplify retrofits and new installations, reducing setup time and mounting complexity for OEMs. The TE N V (TENV) enclosure provides protection in washdown environments, increasing uptime in dairy, meat, and pharmaceutical facilities. Dual voltage capability (230/460 V) supports flexible panel wiring and minimizes harnessing changes across plants. The combination of bare steel frame and bearing design (6205 | Ball) enhances durability, reducing maintenance intervals and service costs. Industry context: these features align with long-life, regulatory-compliant motor solutions suitable for hygienic processing equipment and sanitary conveyors.
