ABB EWDM3714T Washdown Motor - IE3 Premium Efficiency
Part Number: 7BEWDM3714T
Quick Summary
The ABB EWDM3714T washdown motor delivers reliable 10 HP power for demanding food processing, packaging lines, and general washdown environments. OEMs and maintenance teams often struggle with uptime in harsh cleaning cycles and variable loads; this model addresses that with durable TEFC, dual voltage capability, and stock availability across multiple warehouses. With certifications like CSA, CSA EEV, and UR, it offers regulatory confidence while maintaining energy efficiency. The combination of 230/460 V operation, 60 Hz duty, and a robust 215T frame translates into predictable performance, lower total cost of ownership, and faster project timelines for industrial applications.
Product Information
Extended Description
7BEWDM3714T ABB: Washdown Motor 10 Hp 230 V (EWDM3714T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
10HP,1770RPM,3PH,60HZ,215T,3752M,TE
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6307 | Ball
Bearing NDE
6206 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
EWDM3714T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
A
Dimension Diagram
37LYH451: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
Standard
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
215
Frequency (f)
60 Hz
Global Commercial Alias
EWDM3714T
Gross Volume
7561.383 inÂł
Gross Weight
165 lb
Horsepower Rating UL/CSA
10.000 Hp
IC Class
TEFC
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
10HP,1770RPM,3PH,60HZ,215T,3752M,TEFC,F1
Lubrication
For life
Made To Order
No
Medium Description
White Washdown, 10 HP, 1800 RPM, Frame Size 215T, Standard Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (EWDM3714T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
215T
Motor Frame Suffix
T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
10 Hp
Power Factor
85 %
Product Name
White Washdown
Product Net Depth / Length
26.375 in
Product Net Height
17.375 in
Product Net Weight
165 lb
Product Net Width
16.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
25 A | 12.5 A
Rated Efficiency
91.70 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
1.38 in
Short Description
10 HP, 1800 RPM, Frame Size 215T, Standard, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101115
Voltage Code
K
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: 10 HP output with 1770 r/min nominal speed at 60 Hz delivers consistent torque for continuous-motion processes, improving line throughput and reducing cycle times in packaging and filling lines. Application: high-demand conveyors and mixer drives where steadiness matters. Feature → Business Impact → Application: TEFC enclosure and White Washdown construction provide corrosion and washdown resilience, extending service intervals in hygienic environments such as food and beverage lines. Application: meat processing, dairy, and beverage packaging where cleanability is critical. Feature → Business Impact → Application: dual voltage 230/460 V and 3-phase operation simplify electrical design, enabling stock optimization and faster installation across facilities. Application: OEMs seeking flexible sourcing and quick deployment. Feature → Business Impact → Application: IE3 premium efficiency reduces energy consumption by significant margin, lowering operating costs and improving sustainability metrics. Application: continuous operation plants aiming for compliance with energy targets. Feature → Business Impact → Application: Direct On Line starting supports quick commissioning and reduces drive hardware complexity, minimizing start-up time on assembly lines. Application: retrofit projects and new line builds with limited control infrastructure. Feature → Business Impact → Application: 1.15 service factor provides a safe margin against overloads, improving reliability during peak loads. Application: oscillating loads on mixers and grinders. Feature → Business Impact → Application: 0 day lead time and broad warehouse stocking enable rapid fulfillment, reducing downtime and project delays. Application: medical device packaging lines and consumer goods fabrication with tight timelines.
