ABB GNEM3211T General Purpose Motor - IE3 Premium Efficiency
Part Number: 7BGNEM3211T
Quick Summary
ABB GNEM3211T General Purpose Motor delivers 3 HP for 190 V systems in industrial drives. This open, three-phase motor is designed for general purpose conveyors, pumps, and machines where reliable start-up and steady operation are essential. Users frequently contend with mismatched voltages, long lead times, and retrofit challenges; this model mitigates those risks with stock availability across multiple warehouses and a broad voltage range. The design carries CE, UKCA, and UL/UR certifications alongside IE3 efficiency, helping meet modern energy and safety standards. The OPSB enclosure and rugged steel frame simplify installation in harsh environments. With a foot-mounted 182T frame and standard mounting, it enables faster integration and predictable maintenance costs for OEMs and service teams.
Product Information
Extended Description
7BGNEM3211T ABB: General Purpose Motor 3 Hp 190 V (GNEM3211T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
,RPM,0PH,HZ,182T,OPSB,F1,N
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
GNEM3211T
Certification Agency
C UR US | CE | IE3 | UKCA | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
OPSB
Frame Material
Steel
Frame Size
182
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
GNEM3211T
Gross Volume
5274.135 in³
Gross Weight
83 lb
Insulation Class
F
Invoice Description
,RPM,0PH,HZ,182T,OPSB,F1,N
Made To Order
No
Medium Description
General Purpose 3PH Open, 3/2.2 HP, 1800//1500 RPM, Frame Size 182T, Standard Mounting, 3 Phase, OPSB Enclosure, 208-230/460//190/38
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
182T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
74 %
Product Name
General Purpose 3PH Open
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
83 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
9 A | 8.8 A | 4.4 A | 10.2 A | 5.1 A
Rated Efficiency
90.20 %
Rated Speed
1460 r/min | 1760 r/min
Replaced Product ID (OLD)
7B36G548N115G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Short Description
3/2.2 HP, 1800//1500 RPM, Frame Size 182T, Standard, 3 PH, OPSB, 208-230/460//190/380 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min | 1800 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
190 V | 208 V | 230 V | 380 V | 460 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature → Business Impact → Application: IE3 Premium Efficiency delivers energy savings and reduced heat generation, lowering operating costs for continuous-duty applications such as conveyors and pumps. This translates to stronger ROI in facilities prioritizing energy performance, especially where utility incentives favor premium efficiency motors. Feature → Application: 3-phase, 4-pole design with 50/60 Hz compatibility supports both 1460 r/min and 1760 r/min operation, enabling seamless integration into 50 Hz and 60 Hz lines without extensive rewiring. This is ideal for multi-site OEMs and global installations handling diverse electrical grids. Feature → Business Impact → Application: OPSB enclosure and 182T frame ensure rugged readiness and straightforward bolt-on installation, reducing commissioning time and maintenance needs on open-floor machines, fans, and small pumps. Feature → Compatibility → Application: Wide voltage rating (190–460 V) provides cross-market compatibility, minimizing stock variety and simplifying procurement for mixed fleets. Feature → Performance → Application: 1.15 service factor, 83 lb weight, and steel frame support robust startup torque with durable, long-term operation in harsh environments. Feature → Lead Time → Application: Stocked at multiple warehouses with 0 day lead time reduces downtime and accelerates project timelines for OEMs and repair centers, improving overall equipment uptime in manufacturing lines.
