ABB 7BGNEM3554 General Purpose Motor - IE3-Premium
Part Number: 7BGNEM3554
Quick Summary
ABB 7BGNEM3554 General Purpose Motor provides 1.1 kW three-phase power for standard industrial drives across conveyors, pumps, and processing lines. This motor is designed to reduce unplanned downtime and energy waste by delivering consistent torque at rated speeds. It carries multiple certifications relevant to global and compliance-driven projects, including IE3 Premium Efficiency, CE and UKCA marks, and NEMA Premium alignment, supporting cross-border procurement. The rugged TEFC enclosure and steel frame stand up to typical factory environments, while the foot-mounted base and horizontal orientation simplify installation and serviceability. With a wide voltage range (190–460 V) and a 1.15 service factor, it fits existing plant infrastructure and lowers total cost of ownership through longer service life and lower energy use.
Product Information
Extended Description
7BGNEM3554 ABB: General Purpose Motor 1.1 kW 190 V (GNEM3554)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5/1.1KWHP,1755//1445RPM,3PH,60//5
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
GNEM3554
Certification Agency
CE | CURUSEEV | IE3 | NEMA_PREMIUM | UKCA | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Global Commercial Alias
GNEM3554
Gross Weight
41 lb
Insulation Class
F
Invoice Description
1.5/1.1KWHP,1755//1445RPM,3PH,60//50HZ,5
Made To Order
No
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1.1 kW | 1.5 Hp
Power Factor
80 %
Product Name
GP 3PH Enclosed
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
41 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.6 A | 2.3 A | 5.4 A | 2.7 A
Rated Efficiency
86.5 %
Rated Speed
1445 r/min | 1755 r/min
Replaced Product ID (OLD)
7B35A011Z801G2
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States
Synchronous Speed (vsyn)
1500 r/min | 1800 r/min
Type of Duty
Continuous
Voltage Rating
190 V | 208 V | 230 V | 380 V | 460 V
Feature → Business Impact → Application: The 1.1 kW output combined with a 1.15 service factor improves overload resilience, reducing the risk of stalling during peak loads in conveyors and pumps. This translates to higher line throughput and fewer emergency maintenance events in continuous-duty applications. The IE3 Premium efficiency rating, with an efficiency of 86.5%, delivers measurable energy savings across rotating equipment fleets, lowering operating costs for long-running processes and reducing carbon footprint in food processing, packaging lines, and material handling. The TEFC enclosure (Totally Enclosed Fan-Cold) and steel frame provide robust protection against dust, moisture, and humidity, enabling reliable operation in harsh factory environments and enabling longer service intervals in cement, mining, and water-treatment facilities. The foot-mounted base, horizontal mounting, and 56 frame size simplify installation, reduce commissioning time, and support straightforward alignment with existing gearboxes and drives. With multiple voltage options (190–460 V) and direct-on-line starting, this motor pairs with common VFDs and hard-wired starter panels, ensuring quick retrofits and compatibility with legacy equipment. Bearing design (6205 ball) and insulation class F contribute to extended life in moderate ambient temperatures up to 40 °C, lowering spare-part consumption and replacement costs in multi-shift operations. Industry-specific notes: the motor’s NEMA-related design and wide stock availability (US, GB, SG, and China warehouses) support fast procurement for project-based maintenance and OEM integrations, reducing total cost of ownership and improving uptime in automotive assembly lines, process cooling, and packaging systems.
Get a Quick Quote for a ABB 7BGNEM3554
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BGNEM3554?
Enquire Now
FAQs
The motor is a 3-phase unit with a broad voltage rating of 190 V, 208 V, 230 V, 380 V, and 460 V, enabling compatibility with diverse plant electrical systems. It supports direct-on-line starting and is designed for straightforward integration with standard VFDs or hard-wired starters, simplifying retrofits and new installations alike.
The motor delivers IE3 Premium efficiency with an average efficiency of 86.5% and a service factor of 1.15, allowing reliable overload tolerance. This combination reduces energy consumption during continuous operation and improves uptime in conveyors, pumps, and fans without compromising performance.
Yes. With a 4-pole design, continuous-duty ratings, and a robust TEFC enclosure, the 7BGNEM3554 is well-suited for long-running conveyor and pump duty cycles. The 1.15 service factor provides additional headroom for transient loads, minimizing nuisance trips and improving process stability.
The motor carries CE, UKCA, IE3, and NEMA Premium efficiency designations, along with CURUSEEV and WEEE marks. These certifications support global procurement, energy compliance, and safe operation across regions, reducing the need for additional custom approvals during project execution.
The motor is foot-mounted, horizontally oriented, and built around a 56 frame with TEFC protection, facilitating quick installation and alignment with existing gearboxes. Bearings are 6205 ball type, insulation is class F, and ambient operating up to 40 °C, all contributing to extended service life, lower maintenance costs, and faster time-to-value in multi-shift manufacturing environments.
