ABB GNEM3611T General Purpose Motor - IE3 Premium Efficiency
Part Number: 7BGNEM3611T
Quick Summary
The ABB GNEM3611T General Purpose Motor delivers reliable 3 HP power for industrial conveyors, fans, and pumps. Engineered for straightforward OEM integration, it reduces downtime with a sturdy 182T frame and horizontal foot mounting. Key certifications include IE3 premium efficiency, CE, CSA, UR, and WEEE, aligning with contemporary safety and environmental standards. With a TEFC enclosure, 190-460 V multi-voltage options, and a robust steel frame, it delivers predictable performance across operating conditions. Choosing this motor helps you meet energy targets, simplify procurement across global sites, and improve overall equipment reliability.
Product Information
Extended Description
7BGNEM3611T ABB: General Purpose Motor 3 Hp 190 V (GNEM3611T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
3HP,1760//1460RPM,3PH,60//50HZ,182T
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
GNEM3611T
Certification Agency
CE | CSA | IE3 | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
182
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
GNEM3611T
Gross Volume
5274.135 in³
Gross Weight
83 lb
Insulation Class
F
Invoice Description
3HP,1760//1460RPM,3PH,60//50HZ,182T,3636
Made To Order
No
Medium Description
General Purpose 3PH Enclosed, 3/2.2 HP, 1800//1500 RPM, Frame Size 182T, Standard Mounting, 3 Phase, TEFC Enclosure, 208-230/460//19
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
182T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
74 %
Product Name
General Purpose 3PH Enclosed
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
83 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
9 A | 8.8 A | 4.4 A | 10.2 A | 5.1 A
Rated Efficiency
90.20 %
Rated Speed
1460 r/min | 1760 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Short Description
3/2.2 HP, 1800//1500 RPM, Frame Size 182T, Standard, 3 PH, TEFC, 208-230/460//190/380 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min | 1800 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
190 V | 208 V | 230 V | 380 V | 460 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
IE3 Premium Efficiency reduces energy consumption and heat in continuous operation. This translates to lower operating costs and easier compliance with energy regulations, making it ideal for conveyors, process pumps, and fans in manufacturing lines. TEFC enclosure and a sturdy 182T steel frame provide robust protection against dust and moisture, extending motor life and simplifying maintenance planning in harsh environments such as packaging and metalworking. The wide voltage range (190-460 V) and 50/60 Hz compatibility simplify procurement and installation, enabling a single motor to serve multiple sites and retrofit projects. Direct-on-line starting and a four-pole design offer reliable startup torque with minimal control complexity, reducing hardware needs and enabling faster line ramping for conveyors, mixers, and ventilation applications. Durable bearings (6206 ball), a 1.13 in shaft, and a weight of 83 lb support long life and smoother operation in continuous-duty service, while stock availability across multiple warehouses shortens lead times for project pipelines.
