ABB GNEM3615T-G Shaft Ground Motor - IE3 Premium
Part Number: 7BGNEM3615T-G
Quick Summary
Shaft Ground Motor from ABB GNEM3615T-G provides reliable three-phase power for conveyors and packaging lines. Users contend with grounding noise, EMI, and downtime when drives aren’t compatible with harsh environments; this motor minimizes that risk with shaft grounding and a TEFC enclosure. It features IE3 premium efficiency alongside global certifications such as CE, CSA, and UR, supporting regulatory compliance and safer operation. With a rugged 184T frame, foot mounting, and direct-on-line starting, it streamlines installation and reduces total cost of ownership for OEMs and system integrators.
Product Information
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1750//1440RPM,3PH,60//50HZ,184T
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
GNEM3615T-G
Certification Agency
CE | CSA | IE3 | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
184
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
GNEM3615T-G
Gross Volume
7192.91 in³
Gross Weight
101 lb
Insulation Class
H
Invoice Description
5HP,1750//1440RPM,3PH,60//50HZ,184T,3646
Made To Order
No
Medium Description
Shaft Ground, 5/3.7 HP, 1800//1500 RPM, Frame Size 184T, Standard Mounting, 3 Phase, TEFC Enclosure, 208-230/460//190/380 V, 50 Hz (
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
78 %
Product Name
Shaft Ground
Product Net Depth / Length
26.625 in
Product Net Height
16.25 in
Product Net Weight
101 lb
Product Net Width
16.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
14 A | 13 A | 6.6 A | 15.4 A | 7.7 A
Rated Efficiency
90.20 %
Rated Speed
1440 r/min | 1750 r/min
Replaced Part Number (OLD)
7B36M524R014G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Shaft Grounding
Shaft Grounding
Short Description
5/3.7 HP, 1800//1500 RPM, Frame Size 184T, Standard, 3 PH, TEFC, 208-230/460//190/380 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min | 1800 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
190 V | 208 V | 230 V | 380 V | 460 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature: Shaft grounding reduces stray currents and electrical noise, improving bearing life and equipment reliability. Business Impact: Lower maintenance costs and less downtime in harsh environments. Application: Conveyor systems and material handling lines where grounding integrity is critical. Feature: IE3 Premium Efficiency delivers higher efficiency under continuous load. Business Impact: Lower energy bills and cooler motor operation, extending motor life. Application: Any 3-phase process line in manufacturing, especially long-running operations. Feature: 184T frame with foot mounting simplifies retrofits and new installations. Business Impact: Faster installations, better spare-part compatibility, and reduced commissioning time. Application: OEM equipment, pumps, and packaging machines that reuse standard frame assemblies. Feature: TEFC enclosure provides robust protection against dust and moisture. Business Impact: Extended mean time between failures in dusty or humid plants, reducing service intervals. Application: Cement, mining, and metalworking facilities with challenging atmospheres. Feature: Wide voltage and frequency range (190–460V, 50/60Hz) enables regional flexibility. Business Impact: Lower stocking costs and quicker global deployment. Application: Multinational plants and integrator projects. Feature: Direct-on-line starting simplifies drive control and reduces startup transients. Business Impact: Lower control hardware requirements and faster ramp times. Application: High-cycle conveyors and presses that demand immediate torque.
Get a Quick Quote for a ABB 7BGNEM3615T-G
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BGNEM3615T-G?
Enquire Now
FAQs
Plan for a horizontal, foot-mounted installation using the 184T frame with a TEFC enclosure. Ensure direct on line starting capability is available on the control panel. Verify the motor can handle continuous duty and ambient temperatures up to 40°C, and confirm the shaft grounding connection is properly bonded to the machine frame to minimize EMI and bearing wear.
The motor supports a broad voltage range of 190–460V and both 50 Hz and 60 Hz operation, enabling multi-region deployment. It is a three-phase design with a 4-pole configuration, rated for continuous service, and rated currents that vary with voltage and speed. This flexibility reduces stocking requirements when supplying equipment across global sites.
Yes. The motor is designed for continuous duty with a robust TEFC enclosure and shaft grounding to handle long run times and demanding loads. Its 5 HP output, 184T frame, and IE3 efficiency help minimize energy costs while maintaining reliable torque delivery at 1440/1750 r/min depending on speed conditions.
The GNEM3615T-G carries CE, CSA, IE3, UR, and WEEE certifications, ensuring compliance across major markets. This simplifies customer approvals, reduces the need for on-site re-certification, and supports safer operation in regulated environments such as food processing, packaging, and automotive assembly lines.
IE3 premium efficiency lowers energy consumption in continuous operation, delivering tangible savings over the motor’s life. Shaft grounding reduces bearing wear and electrical noise that can cause premature faults. Together, these features decrease maintenance intervals and unplanned downtime, providing a favorable total cost of ownership for OEMs and end users.
