ABB 7BHBEM2333T Motors & Drives - Premium Efficiency
Part Number: 7BHBEM2333T
Quick Summary
ABB 7BHBEM2333T is a high-efficiency motor delivering 15 HP for critical cooling systems in industrial equipment. This design helps engineers reduce downtime and streamline retrofits by aligning with common 230/460 V 3-phase supply and a compact 254T frame. Manufacturers often struggle with long lead times, mismatched mounting, and supply chain gaps when upgrading cooling-driven motors; this model aims to minimize those challenges with stock at multiple warehouses and a straightforward Direct on Line start. It holds NEMA Premium Efficiency certification, CURUSEEV, and WEEE compliance, reinforcing regulatory alignment. The horizontal foot-mount orientation, TEFC enclosure, and 60 Hz operation support quick installation, while industry-standard shaft dimensions and bearings ensure reliable long-term operation and simplified maintenance across HVAC, processing, and machine-tool applications.
Product Information
Extended Description
7BHBEM2333T ABB: Critical Cooling 15 Hp 230 V (HBEM2333T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
44M 4P TEFC HOR 254T
Ambient Temperature
40 °C
Bearing
6309, Sealed Bearing
Bearing NDE
6208
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
HBEM2333T
Certification Agency
CURUSEEV | NEMA_PREMIUM | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Iron
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
HBEM2333T
Gross Volume
9651.933 in³
Gross Weight
268 lb
Insulation Class
H
Invoice Description
44M 4P TEFC HOR 254T
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
Critical Cooling, 15 HP, 1800 RPM, Frame Size 254T, Standard Mounting, 3 Phase, 230/460 V, 60 Hz (HBEM2333T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
254T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
15 Hp
Power Factor
83 %
Product Name
Critical Cooling
Product Net Depth / Length
27 in
Product Net Height
17.438 in
Product Net Weight
268 lb
Product Net Width
20.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
36.2 A | 18.1 A
Rated Efficiency
92.40 %
Rated Speed
1765 r/min
Replaced Product ID (OLD)
7B09T115T597G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.63 in
Short Description
15 HP, 1800 RPM, Frame Size 254T, Standard, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The 15 HP output and rated speed of 1765 r/min deliver robust cooling-capable performance for continuous operation, reducing energy use and improving process stability in industrial chillers and heat-exchange systems. This translates to tangible energy savings and lower operating costs over the motor’s life, especially in large facilities with multiple cooling loops. Application: HVAC and process equipment that require dependable torque at moderate loads gain predictable performance with direct-on-line starting, minimizing commissioning time on new or retrofit projects. Feature → Business Impact → Application: The 254T frame and TEFC enclosure provide a compact footprint with proven protection in harsh environments; technicians benefit from easier installation and maintenance while equipment breathes easier under 60 Hz power. Application: retrofits in machine tools and packaging lines where space is at a premium and reliability is critical. Feature → Business Impact → Application: 230/460 V dual-voltage capability and three-phase operation support flexible site wiring and future expansion plans, reducing spare-part complexity and allowing phased modernization without a full electrical redesign. Application: upgrades to aging plant motors within continuous-process lines. Feature → Business Impact → Application: Premium efficiency rating (92.40%) translates to measurable long-term energy savings, supporting sustainability targets and lowering total cost of ownership; this is particularly valuable for facilities operating under strict energy-use mandates. Application: energy-conscious HVAC and industrial process applications. Feature → Business Impact → Application: Stocked at multiple warehouses with 0-day lead time ensures rapid fulfillment, reducing downtime and accelerating project timelines for critical cooling deployments. Application: capital-intensive retrofit programs and new-build installations. Feature → Business Impact → Application: NEMA Design Code A, 1.15 service factor, and high-quality bearings (6309) extend motor life and reduce maintenance intervals, delivering lower maintenance costs and higher uptime across harsh industrial environments. Application: heavy-duty production and continuous-duty cooling equipment. The combination of frame size, mounting orientation, and shaft dimensions supports straightforward alignment with existing couplings and belts, enabling smoother integration in brownfield facilities and new builds alike.
