ABB HBEM2334T Motor - 20 HP TEFC 60 Hz, NEMA Premium
Part Number: 7BHBEM2334T
Quick Summary
ABB HBEM2334T motor provides 20 HP cooling capability for critical process cooling applications. When overheating threatens uptime, reliable performance and fast start-up become essential to protect production lines. This motor carries NEMA Premium efficiency with a TEFC enclosure and 60 Hz operation, offering energy savings and durable service in demanding environments. It also aligns with CUR/US EEV and WEEE certifications, supporting compliance initiatives. With its 3-phase design, dual voltage rating (230/460 V), and compact 256T frame, it delivers flexible integration, scalable power, and lower total cost of ownership for industrial cooling systems. For procurement teams, stock availability is confirmed across multiple warehouses, ensuring faster access and reduced lead times.
Product Information
Extended Description
7BHBEM2334T ABB: Critical Cooling 20 Hp 230 V (HBEM2334T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
60M 4P TEFC HOR 256T
Ambient Temperature
40 °C
Bearing
6309, Sealed Bearing
Bearing NDE
6208
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
HBEM2334T
Certification Agency
CURUSEEV | NEMA_PREMIUM | WEEE
Country of Origin
United States (US)
Customs Tariff Number
8466939885
Drive End Flange Type
Standard
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Iron
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
HBEM2334T
Gross Volume
9651.933 in³
Gross Weight
322 lb
Insulation Class
H
Invoice Description
60M 4P TEFC HOR 256T
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
Critical Cooling, 20 HP, 1800 RPM, Frame Size 256T, Standard Mounting, 3 Phase, 230/460 V, 60 Hz (HBEM2334T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
256T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
20 Hp
Power Factor
83 %
Product Name
Critical Cooling
Product Net Depth / Length
27 in
Product Net Height
17.438 in
Product Net Weight
322 lb
Product Net Width
20.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
48 A | 24 A
Rated Efficiency
93 %
Rated Speed
1770 r/min
Replaced Product ID (OLD)
7B09T116T459G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.63 in
Short Description
20 HP, 1800 RPM, Frame Size 256T, Standard, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature: TEFC enclosure provides enhanced protection against dust, moisture, and airborne contaminants, extending motor life in harsh plants. Business Impact: reduces maintenance frequency and unplanned downtime, cutting total cost of ownership. Application: ideal for outdoor fans, cooling towers, and rugged process equipment that require robust sealing. Feature: 256T frame with foot-mounted base enables straightforward installation and retrofit into existing baselines. Business Impact: simplifies mechanical integration, ensures correct alignment, and lowers installation labor. Application: retrofit projects and new builds with limited space. Feature: dual voltage 230/460 V and 60 Hz operation simplifies electrical design, allowing a single stock line to serve multiple sites. Business Impact: lowers inventory complexity and wiring errors, reducing commissioning time. Application: plant-wide cooling loops and pumps using standard 3-phase power. Feature: direct-on-line starting and 3-phase reliability deliver consistent torque and startup performance. Business Impact: minimizes starter hardware and accelerates ramp-up, improving line throughput. Application: conveyors, fans, and blowers in continuous duty cooling systems. Feature: premium efficiency and service factor 1.15 improve energy performance and motor longevity. Business Impact: energy cost savings over lifecycle and better load handling. Application: long-running cooling loops and continuous duty motors in industrial facilities. Feature: stock availability and international sourcing support rapid deployment. Business Impact: reduces spare-part lead times and supports global projects. Application: multinational manufacturing environments requiring rapid replacement.
Get a Quick Quote for a ABB 7BHBEM2334T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BHBEM2334T?
Enquire Now
FAQs
Yes. The HBEM2334T uses a 256T frame and a foot-mounted base with horizontal mounting (F1). It supports direct-on-line starting, operates on 230/460 V at 60 Hz, and provides a robust TEFC enclosure for demanding environments. Ensure proper shaft diameter (1.63 in) and adequate cooling during installation.
The motor delivers 20 HP with a 1.15 service factor, running at 60 Hz in a 3-phase configuration. It is compatible with dual voltage 230/460 V and has a rated current of 48 A (nominal) and 24 A for low-load operation. The synchronous speed is 1800 r/min with a practical operating speed of about 1770 r/min.
Absolutely. Designed for critical cooling, this TEFC, 3-phase induction motor provides reliable torque and consistent operation at 20 HP. With premium efficiency and a robust enclosure, it is well-suited for cooling towers, process cooling circuits, and air handling equipment in demanding facilities.
HBEM2334T carries NEMA Premium efficiency recognition, plus CUR/US EEV compliance and WEEE stewardship. These certifications support energy efficiency targets, regulatory requirements, and end-of-life compliance, aiding procurement in meeting sustainability and reliability standards across global operations.
The HBEM2334T is stocked at multiple warehouses (US, China, GB, SG) with zero lead time listed for ready-to-ship orders. Minimum order quantity is 1 piece, enabling rapid deployment for maintenance and project kick-offs. This global availability helps minimize downtime and supports fast replacement in multinational facilities.
