ABB HBEM3558T Motor - Premium Efficiency (NEMA 12-12)
Part Number: 7BHBEM3558T
Quick Summary
ABB HBEM3558T motor is a high-efficiency cooling motor for continuous service in industrial cooling systems. Operators often face energy waste and downtime when cooling motors are undersized or misapplied to load profiles. This model aligns with NEMA Premium efficiency, CURUSEEV, and WEEE certifications, delivering reliable performance in demanding plant environments. Built around a 145T frame and a 230/460 V, three-phase supply, it supports straightforward, foot-mounted horizontal installation. In practice, operators gain lower energy costs, longer motor life, and simplified spare-parts planning, enabling better maintenance scheduling and improved ROI for critical cooling applications.
Product Information
Extended Description
7BHBEM3558T ABB: Critical Cooling 2 Hp 230 V (HBEM3558T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
28M 4P TEFC HOR 145T
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
HBEM3558T
Certification Agency
CURUSEEV | NEMA_PREMIUM | WEEE
Country of Origin
United States (US)
Customs Tariff Number
84149000
Drive End Flange Type
Standard
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
HBEM3558T
Gross Volume
3496.049 in³
Gross Weight
64 lb
Insulation Class
H
Invoice Description
28M 4P TEFC HOR 145T
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
Critical Cooling, 2 HP, 1800 RPM, Frame Size 145T, Standard Mounting, 3 Phase, 230/460 V, 60 Hz (HBEM3558T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
145T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
77 %
Product Name
Critical Cooling
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
64 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.6 A | 2.8 A
Rated Efficiency
86.50 %
Rated Speed
1760 r/min
Replaced Product ID (OLD)
7B35E5738G073G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Short Description
2 HP, 1800 RPM, Frame Size 145T, Standard, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: This 2 HP, 1760 r/min, 60 Hz, 230/460 V three-phase motor delivers reliable drive for cooling fans and pumps, improving control precision and reducing load fluctuations. Business impact: lower energy consumption and cooler equipment margins, thanks to premium efficiency at 86.50% and service factor 1.15. Application: suitable for continuous duty in HVAC and manufacturing cooling loops, with predictable torque and longer motor life. Feature: TEFC enclosure; Impact: protects the windings from dust, moisture and contaminants, extending service life in harsh plant environments; Application: dusty or wet production lines. Feature: Foot-mounted 145T frame with horizontal orientation; Impact: simplifies installation and retrofit compatibility with existing bases; Application: plant retrofits or new equipment in limited space. Feature: Bearing data and insulation class H; Impact: reliable operation at ambient up to 40 °C, reduced maintenance; Application: hot facilities or outdoors where heat loads are high. Feature: Stocked at multiple warehouses and 0 day lead time; Impact: improves uptime and responsiveness for maintenance and spares; Application: time-critical production lines and shutdowns.
