ABB HBEM3704T Motor - TEFC 3 HP NEMA Premium IE3
Part Number: 7BHBEM3704T
Quick Summary
HBEM3704T motor by ABB delivers 3 HP TEFC performance for critical cooling in industrial fans. Engineers frequently face long lead times and stock gaps; this model ships with 0 day lead time and broad warehouse coverage. Stocked at multiple warehouses including US and China with fast fulfillment, it reduces downtime and accelerates project timelines. It carries NEMA Premium IE3 efficiency, a TEFC enclosure, and WEEE/CUR certifications for compliance, while a 213T frame, 230/460 V operation, and direct-on-line start support easy integration. Designed for continuous duty in demanding environments, it offers dependable heat dissipation, sealed bearings, and a service factor of 1.15 to handle startup surges.
Product Information
Extended Description
7BHBEM3704T ABB: Critical Cooling 3 Hp 230 V (HBEM3704T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
38M 6P TEFC HOR 213T
Ambient Temperature
40 °C
Bearing
6307, Sealed Bearing
Bearing NDE
6206
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
HBEM3704T
Certification Agency
CURUSEEV | NEMA_PREMIUM | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
HBEM3704T
Gross Volume
7192.91 in³
Gross Weight
138 lb
Insulation Class
H
Invoice Description
38M 6P TEFC HOR 213T
Made To Order
No
Maximum Speed
1800 r/min
Medium Description
Critical Cooling, 3 HP, 1200 RPM, Frame Size 213T, Standard Mounting, 3 Phase, 230/460 V, 60 Hz (HBEM3704T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
213T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
68 %
Product Name
Critical Cooling
Product Net Depth / Length
26.625 in
Product Net Height
16.25 in
Product Net Weight
138 lb
Product Net Width
16.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
9.2 A | 4.6 A
Rated Efficiency
89.50 %
Rated Speed
1160 r/min
Replaced Product ID (OLD)
7B37T556S519G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.38 in
Short Description
3 HP, 1200 RPM, Frame Size 213T, Standard, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
TEFC enclosure shields the motor from dust and moisture, increasing service life in tough environments. This reduces maintenance intervals and unplanned downtime on critical cooling fans and pumps. The rugged TEFC design pairs with 60 Hz operation and a 213T frame to ensure reliable performance in industrial HVAC and process equipment. IE3 efficiency with NEMA Premium designation reduces energy consumption, lowering operating costs and supporting regulatory compliance for continuous duty applications. The premium efficiency improves power factor and aligns with energy standards, beneficial for facilities aiming for lower total cost of ownership. The 213T frame size and foot-mounted, horizontal mounting simplify installation and retrofit projects, minimizing risk and shortening commissioning times for conveyors, blowers, and pumps. Dual voltage 230/460 V at 60 Hz provides cross-site compatibility for global plants, reducing transformer needs and simplifying spares management. Rated current of 9.2 A / 4.6 A and a service factor of 1.15 support reliable performance during startup and peak loads, while direct on line starting minimizes control hardware requirements. Stocked at multiple warehouses worldwide with fast fulfillment and 0 day lead time means faster project ramp and lower risk of production delays.
Get a Quick Quote for a ABB 7BHBEM3704T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BHBEM3704T?
Enquire Now
FAQs
The HBEM3704T uses a foot-mounted configuration with a horizontal mounting orientation and a 213T frame. This footprint is designed for straightforward retrofit and fits common conveyor, blower, and pump assemblies, minimizing rework and enabling quick commissioning in existing footprints.
This is a 3-phase motor rated for 230 V or 460 V at 60 Hz, with rated currents of 9.2 A and 4.6 A respectively. It supports direct on line starting, simplifying control wiring and reducing soft-start requirements in standard process lines.
Yes. Designed for continuous duty, it features IE3 efficiency and a TEFC enclosure that withstands demanding environments, delivering reliable cooling performance in HVAC fan systems, pumps, and associated process equipment with stable operation over long cycles.
The motor carries NEMA Premium IE3 efficiency, CUR/USEEV compliance, and WEEE markings, supporting energy efficiency mandates and environmental requirements across North America and Europe, ensuring smoother regulatory acceptance for new installations.
It is stocked at multiple warehouses worldwide with 0 day lead time, including locations in the US, China, and other regions. This setup facilitates rapid fulfillment and reduces project delays on critical cooling equipment deployments.
