ABB IDCSWDM3546T Washdown Motor - IE3 Premium
Part Number: 7BIDCSWDM3546T
Quick Summary
Washdown motor ABB IDCSWDM3546T delivers dependable 1 HP performance for hygienic manufacturing environments such as food processing, beverage, pharma, and packaging lines. Designed to withstand repeated CIP washdowns, it maintains steady torque and uptime even in harsh conditions. The motor carries IE3 premium efficiency and a stainless steel frame to reduce energy waste and corrosion risk over its life cycle. Its TE N V enclosure, C‑Face drive end flange, and horizontal foot-mounted configuration simplify installation in tight spaces and direct-drive setups. With 230/460 V, 60 Hz three-phase power and stock availability across multiple warehouses, this solution supports fast procurement and predictable maintenance schedules.
Product Information
Extended Description
7BIDCSWDM3546T ABB: Washdown Motor 1 Hp 230 V (IDCSWDM3546T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,1770RPM,3PH,60HZ,143TC,3522M,TE
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDCSWDM3546T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
B
Dimension Diagram
35LYSS597: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Stainless Steel
Frame Size
143
Frequency (f)
60 Hz
Global Commercial Alias
IDCSWDM3546T
Gross Volume
2110.969 inÂł
Gross Weight
42 lb
Horsepower Rating UL/CSA
1.000 Hp
IC Class
TENV
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
H
Invoice Description
1HP,1770RPM,3PH,60HZ,143TC,3522M,TENV,F1
Lubrication
Regreasable
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
Paint-Free Washdown, 1 HP, 1800 RPM, Frame Size 143Tc, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (IDCSWDM3546T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
143TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
66 %
Product Name
Paint-Free Washdown
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
42 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.34 A | 1.67 A
Rated Efficiency
85.50 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.88 in
Short Description
1 HP, 1800 RPM, Frame Size 143Tc, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101112
Voltage Code
M
Voltage Rating
230 V | 460 V
Paint-free washdown capability with a stainless steel frame provides superior corrosion resistance, reducing maintenance costs and extending service life in CIP environments. This translates to fewer unplanned outages on food processing lines and pharmaceutical packaging equipment. IE3 premium efficiency paired with a 1 HP rating delivers meaningful energy savings and cooler operation, supporting longer runs on conveyor and pump systems while meeting modern sustainability targets. The motor’s 230/460 V, 60 Hz three-phase configuration enables flexible integration across plant power architectures and enables direct-on-line starting to minimize control hardware and startup time. TE N V enclosure, NEMA design B, 143TC frame, and C-face drive end flange offer robust protection and straightforward alignment with standard drives and gear heads for hygienic applications. Stocked at multiple warehouses with 0-day lead times, the IDCSWDM3546T supports rapid replacements and reduced downtime on high-throughput production lines. Lubrication is regreasable and bearings are sealed (6205), promoting lower maintenance intervals and extended service life in demanding wash-down environments.
