ABB 7BIDDRPM18304C AC Motor - 30HP, 460V, C-Face
Part Number: 7BIDDRPM18304C
Quick Summary
RPMAC 30 HP motor by ABB delivers robust drive performance for heavy-duty conveyors and process equipment. Engineers often grapple with torque variability, high energy use, and downtime when selecting a motor for demanding automation lines. This laminated-frame, 3-phase AC motor is rated for 60 Hz at 460 V and carries UL/UR recognition with C-Face mounting, offering certified reliability and easy mechanical fit. Designed for 40 °C ambient operation and the DPFV enclosure, it supports rugged industrial environments while providing consistent performance and longer service life. Together, these features reduce total cost of ownership and accelerate project timelines by simplifying procurement, installation, and service across automation projects.
Product Information
Extended Description
7BIDDRPM18304C ABB: AC VS Laminated Frame - RPMAC 30 Hp 460 V (IDDRPM18304C)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
30HP,1745RPM,3PH,60HZ,1852C,DPG-FV,
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
45BC02JPP30A, Ball
Bearing NDE
35BC02JPP30A
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDDRPM18304C
Certification Agency
CCSA US | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
616779-050
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Electrical Data
Enclosure Type
DPFV
Frame Material
Laminated
Frame Size
1852
Frequency (f)
60 Hz
Global Commercial Alias
IDDRPM18304C
Gross Volume
23313.375 inÂł
Gross Weight
120.655 kg
Horsepower Rating UL/CSA
30.000 Hp
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
Insulation Class
H
Invoice Description
30HP,1745RPM,3PH,60HZ,1852C,DPG-FV,FT/2
Made To Order
No
Medium Description
AC VS Laminated Frame - RPMAC, 30 HP, 1800/3600 RPM, Frame Size Fl1852Cz, C-Face Mounting, 3 Phase, DPFV Enclosure, 460 V, (IDDRPM18
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
FL1852CZ
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
3
Number of Poles (High)
4
Order Multiple
1 piece
Output Power
30 Hp
Product Name
AC VS Laminated Frame - RPMAC
Product Net Depth / Length
34.5 in
Product Net Height
25.5 in
Product Net Weight
120.655 kg
Product Net Width
26.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
39 A
Rated Speed
1745 r/min | 2300 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
1.63 in
Short Description
30 HP, 1800/3600 RPM, Frame Size Fl1852Cz, C-Face, 3 PH, DPFV, 460 V
Standards
NEMA
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
460 V
Feature: Laminated frame construction with a 40 °C ambient rating enables efficient heat management and lower core losses. Business Impact: Improves energy efficiency, reduces thermal wear, and extends motor life, lowering maintenance costs over the long run. Application: ideal for high-cycle industrial automation lines and conveyors that demand steady torque and reliability. Feature: 3-phase, 460 V, 60 Hz supply aligns with standard plant power, simplifying electrical design and control panel integration. Business Impact: minimizes wiring complexity and energy waste while accelerating installation. Application: general manufacturing equipment and process automation. Feature: DPFV enclosure with C-Face mounting and foot-mounted base (Frame FL1852CZ) provides rugged protection and flexible installation. Business Impact: enhances durability in dirty environments and enables quick retrofits. Application: material handling, packaging, and machine tooling. Feature: Rated speeds of 1745 r/min and 2300 r/min offer multi-speed capability and torque flexibility. Business Impact: supports varied loads and processes without overhauling drive systems. Application: conveyors, fans, and mixers. Feature: Stocked at multiple warehouses with 0-day lead time and strong certifications (NEMA-aligned, UL/UR recognized). Business Impact: reduces project downtime and procurement risk. Application: just-in-time automation projects and fast deployments across facilities.
